5SHX1445H0001 ABB直流接触器 控制卡 智能备件模块

5SHX1445H0001 ABB直流接触器 控制卡 智能备件模块

结构原件

可控硅是P1N1P2N2四层三端结构元件，共有三个PN结，分析原理时，可以把它看作由一个PNP管和一个NPN管所组成，其等效图解如右图所示。双向可控硅：双向可控硅是一种硅可控整流器件，也称作双向晶闸管。这种器件在电路中能够实现交流电的无触点控制，以小电流控制大电流，具有无火花、动作快、寿命长、可靠性高以及简化电路结构等优点。从外表上看，双向可控硅和普通可控硅很相似，也有三个电极。

但是，它除了其中一个电极G仍叫做控制极外，另外两个电极通常却不再叫做阳极和阴极，而统称为主电极Tl和T2。它的符号也和普通可控硅不同，是把两个可控硅反接在一起画成的，如图2所示。它的型号，在我国一般用“3CTS”或“KS”表示；国外的资料也有用“TRIAC”来表示的。双向可控硅的规格、型号、外形以及电极引脚排列依生产厂家不同而有所不同，但其电极引脚多数是按T1、T2、G的顾序从左至右排列（观察时，电极引脚向下，面对标有字符的一面）。

晶闸管

晶闸管（Thyristor）是晶体闸流管的简称，又被称做可控硅整流器，以前被简称为可控硅；1957年美国通用电气公司开发出世界上款晶闸管产品，并于1958年将其商业化；晶闸管是PNPN四层半导体结构，它有三个极：阳极，阴极和控制极； 晶闸管具有硅整流器件的特性，能在高电压、大电流条件下工作，且其工作过程可以控制、被广泛应用于可控整流、交流调压、无触点电子开关、逆变及变频等电子电路中。

5SHX1445H0001 ABB直流接触器 控制卡 智能备件模块


Structural element

The thyristor is a P1N1P2N2 four-layer three-terminal structural element with a total of three PN junctions. When analyzing the principle, it can be regarded as composed of a PNP tube and an NPN tube, and its equivalent diagram is shown in the figure on the right. Bidirectional thyristor: Bidirectional thyristor is a silicon controllable rectifier device, also known as bidirectional thyristor. This device can realize the contactless control of alternating current in the circuit, and control the large current with small current. It has the advantages of no spark, fast action, long life, high reliability and simplified circuit structure. From the appearance, the bidirectional thyristor is very similar to the ordinary thyristor, and also has three electrodes.

However, in addition to one of the electrodes G is still called the control pole, the other two electrodes are usually no longer called the anode and cathode, but collectively referred to as the main electrode Tl and T2. Its symbol is also different from ordinary thyristors, which is drawn by connecting two thyristors together, as shown in Figure 2. Its model is commonly used in our country as "3CTS" or "KS"; Foreign data are also represented by "TRIAC". The specifications, models, shapes and electrode pin arrangement of bidirectional SCR vary according to the manufacturer, but most of its electrode pins are arranged from left to right in the order of T1, T2, G (when observed, the electrode pins are down, facing the side marked with characters).

thyristor

Thyristor (Thyristor) is short for crystal thyristor, also known as thyristor rectifier, previously referred to as thyristor; In 1957, the United States General Electric Company developed the world's first thyristor product, and commercialized it in 1958; The thyristor is a PNPN four-layer semiconductor structure, which has three poles: anode, cathode and control pole; Thyristors have the characteristics of silicon rectifier devices, and can work under high voltage and high current conditions, and its working process can be controlled, and it is widely used in controlled rectifier, AC voltage regulation, contactless electronic switch, inverter and frequency conversion electronic circuits.

5SHX1445H0001 ABB直流接触器 控制卡 智能备件模块
