70BV01C-ES-HESG447260R1 ABB 压力导向称重传感器
除了开/关和启动/停止之外，驱动器还配备了两个附加的停止功能 Off2 和
根据Profibus标准关闭3。Off3 可通过 21.03 紧急停止模式进行扩展，以根据类别 1 执行停止。
连接此功能到急停按钮（off3）没有任何时间延迟。在21.03紧急停止的情况下mode = 斜坡停止 定时继电器 （K15） 必须设置长于 23.23 紧急停止时间。为21.03 急停模式 = 滑行停止 驱动器立即打开电源接触器。
Off2 尽可能快地关闭直流电流，并准备驱动器以打开电源接触器或断开电源。对于正常的直流电机负载，强制直流电流的时间零点低于 20 毫秒。此功能应连接到所有信号和安全功能打开电源接触器。此功能对于 4-Q 驱动器非常重要。请勿在期间打开电源接触器再生电流。
70BV01C-ES-HESG447260R1 ABB 压力导向称重传感器
In addition to on/off and start/stop, the drive is equipped with two additional stop functions Off2 and
Closed according to Profibus standard 3. Off3 can be extended with 21.03 Emergency Stop mode to perform a stop according to class 1.
Connect this feature to the emergency stop button (off3) without any time delay. In case of 21.03 emergency stop mode = ramp stop timing relay (K15) must be set longer than 23.23 emergency stop time. For 21.03 SCram mode = Taxi stop drive immediately turn on power contactor.
Off2 turns off the DC current as quickly as possible and prepares the driver to turn on the power contactor or disconnect the power supply. For normal DC motor loads, the time zero of the forced DC current is less than 20 ms. This function should be connected to all signal and safety functions to turn on the power contactor. This feature is very important for 4-Q drives. Do not turn on the power contactor to regenerate current during this period.
70BV01C-ES-HESG447260R1 ABB 压力导向称重传感器
