Modicon 140ACO13000是施耐德电气制造的模拟输出模块。  它是Modicon Quantum ExoStruxure控制系列的一部分，用于隐蔽和模拟I / O模块。  它可以配置UnityPro软件。该装置有八个用于控制和监控电流的模拟输出通道。  它在 4 ...20 毫安， 0 ...20 mA 和 0 ...25 mA 环路。

特征  施耐德电气 140ACO13000 Modicon 模块具有六个可识别功能。

在模块的顶部正面，您可以看到颜色编码的模块编号以及说明。  数字下方是带有 8 个不同指示灯的 LED。  带有客户识别标签的可拆卸门中封闭的是保险丝开口区域。和现场接线端子条。  140ACO13000 LED 在总线通信存在时发出绿色警报。  当检测到模块外部错误时，LED 会发出红色警报。  1...8 在模块输出打开时为绿色，当有通道断线指示时为红色。

此模块的输入范围为 0...25毫安 0...20毫安 4...20毫安。  分辨率为 0...25毫安： 0...25.000 积分 0...20 毫安： 0...20.000 积分 4...20 毫安：   0...16.000 积分(默认) 4...20 毫安： 0...4095分。通道之间没有隔离。  它有 8 个输出字。所需的总线电流为550 mA。它的zui大耗散功率为 5.0 W。  您可以在线修改配置。它通过了 UL 508、CSA 22.2-142、e、FM 1 级 2 区、ATEX 2/22 区认证。

Schneider 140ACO13000 模拟输出模块 I/O 模块

Modicon 140ACO13000 is an analog output module manufactured by Schneider Electric. It is part of the Modicon Quantum ExoStruxure family of controls for concealing and emulating I/O modules. It can configure the UnityPro software. The device has eight analog output channels for controlling and monitoring current. It's in 4... 20 mah, 0... 20 mA and 0... 25 mA loop.

The Schneider Electric 140ACO13000 Modicon module has six identifiable functions.

On the top front of the module, you can see the color-coded module number along with the description. Below the number are leds with eight different indicators. Enclosed in the detachable door with a customer identification tag is the fuse opening area. And field terminal strip. The 140ACO13000 LED emits a green alarm when bus communication is present. When an external module error is detected, the LED emits a red alert. 1... 8 Green when the module output is turned on, red when there is a channel break indication.

The input range for this module is 0... 25 MA 0... 20 mah 4... 20 mah. The resolution is 0... 25 mah: 0... 25.000 points 0... 20 mah: 0... 20.000 points 4... 20 mah: 0... 16.000 points (default) 4... 20 mah: 0... 4095 points. There is no isolation between channels. It has 8 output words. The required bus current is 550 mA. It has a maximum power dissipation of 5.0 W. You can modify the configuration online. It is UL 508, CSA 22.2-142, e, FM Level 1 Zone 2, ATEX 2/22 Zone certified.
