2094-BM01-S 是一款 400VAC 级轴模块，A 系列的连续电流为 6.1 A，峰值电流为 9.2A，B 系列和 C 系列驱动器的峰值电流为 15.3 A，连续输出功率为 3.9 kW。它具有 98% 的效率，对称的短路电流额定值为 200，000 A （rms）。它具有集成分流器，连续功率为 50W，峰值功率为 5.6 kW。该模块的内部分流电阻器的电阻值为 115 欧姆。

模块的工作温度要求为0...50 °C （32...122 °F），相对湿度为 5...95% 无冷凝。它也可以在 1000 米（3281 英尺）的高度无降额和 3000 米（9843 英尺）的降额功能下运行。模块可接受的振动范围为5...55 Hz @ 0.35 毫米（0.014 英寸）双振幅，连续位移;55...500 Hz @ 2.0 g 峰值恒定加速度，而冲击额定值为 15 g，在 11 ms 半正弦脉冲内。

2094-BM01-S 轴模块增强了系统性能和操作安全性。其安全扭矩关闭可提高生产率，同时通过防止电路跳闸时重新启动来减少机器停机时间。13849-BM1-S 已通过 ISO 3-2094 PLe/SIL01 认证，需要外部安全继电器才能满足 EN954-1 3 类工业标准。安全速度监控允许用户监控和降低应用速度以执行工作，而无需关闭整台机器。该驱动器还具有多圈绝 对值编码器，可在电源故障期间保持设备位置。2094-BM01-S 的峰值增强配置可在有限的时间范围内处理需要快速加速和减速的运动应用。这减少了所需的轴模块数量，从而减少了面板空间要求

2094-BM01-S 多轴驱动器 是一个轴模块

The 2094-BM01-S is A 400VAC class shaft module with 6.1A continuous current and 9.2A peak current in the A Series, 15.3A peak current in the B Series and C Series drivers, and 3.9 kW continuous output. It has 98% efficiency and A symmetrical short-circuit current rating of 200,000 A (rms). It has an integrated shunt with a continuous power of 50W and a peak power of 5.6kW. The internal shunt resistor of the module has a resistance value of 115 ohms.

Module operating temperature requirement is 0... 50 °C (32... 122 °F) with a relative humidity of 5... 95% no condensation. It can also operate at altitudes of 1,000 meters (3,281 ft) without derating and 3,000 meters (9,843 ft) with derating functions. The acceptable vibration range of the module is 5... 55 Hz @ 0.35 mm (0.014 in) double amplitude, continuous displacement; 55... 500 Hz @ 2.0g peak constant acceleration, while the impact rating is 15 g, in 11 ms half sinusoidal pulses.

The 2094-BM01-S shaft module enhances system performance and operational safety. Its safe torque shutdown increases productivity while reducing machine downtime by preventing a restart if the circuit trips. The 13849-BM1-S is ISO 3-2094 PLe/SIL01 certified and requires an external safety relay to meet the EN954-1 Category 3 industry standard. Secure speed monitoring allows users to monitor and slow down applications to perform work without shutting down the entire machine. The drive also has a multi-turn absolute encoder that holds the device in place during power failures. The peak enhancement configuration of the 2094-BM01-S handles sports applications that require rapid acceleration and deceleration within a limited time frame. This reduces the number of shaft modules required, thereby reducing panel space requirements
