125840-02是Bently Nevada公司开发的带有RS232/RS422接口的RIMVO模块。它是本特利内华达3500系列的一部分。框架接口模块是3500框架(RIM)的主要接口。它支持用于设置机架和获取机器数据的专用协议。

125840-02功能描述
第 一个机架插槽必须包含RIM(靠近电源)。RIM与TDXnet、TDIX和DDIX Bently Nevada外部通信处理器兼容。

尽管RIM执行一些由整个机架共字的任务，但它不是监控系统的重要组件，对整个系统的正常运行几乎没有影响。每个机架需要一个轮缘。对于使用三模冗余(TMR)的应用，3500系统需要TMR版本的RIM。

TMR RIM除了执行所有其他正常RIMI操作外，还执行“监控通道比较”。配置键锁
肘在“运行”和“程序”模式之间切换3500框架。运行模式阻止配置修改，同时允许机架正常运行。程序模式支持本地和远程机架配置以及标准机架操作。
通过从任—位置的支架上取下钥匙，可以将开关留在运行或程序位置。为防止未经授权的机架重新配置，请将交换机锁定在运行位置。通过将开关锁定在程序位置，可以随时远程配置试管架。

BENTELY 125840-02 振动传感器连接电缆

125840-02 is a RIMVO module with RS232/RS422 interface developed by Bently Nevada. It is part of the Bentley Nevada 3500 series. The Framework interface module is the main interface of the 3500 Framework (RIM). It supports specialized protocols for setting up racks and getting machine data.

125840-02 Function Description
The first rack slot must contain the RIM(near the power supply). RIM is compatible with TDXnet, TDIX, and DDIX Bently Nevada external communications processors.

Although RIM performs some tasks shared by the entire rack, it is not an important component of the monitoring system and has little impact on the normal operation of the overall system. Each frame needs one rim. For applications that use three-mode redundancy (TMR), the 3500 system requires the TMR version of RIM.

TMR RIM performs a "Monitor channel comparison" in addition to all other normal RIMI operations. Configuration key lock
Elbow toggles between "Run" and "Program" modes for 3500 frames. Run mode prevents configuration changes while allowing the rack to run properly. Program mode supports local and remote rack configurations as well as standard rack operation.
The switch can be left in the run or program position by removing the key from the stand in either position. To prevent unauthorized rack reconfiguration, lock the switch in a running position. Test tube racks can be configured remotely at any time by locking the switch in the program position.
