BENTELY 133323-01 通讯网关4通道继电器模块

BENTELY 133323-01 通讯网关4通道继电器模块

产品介绍:

4通道继电器模块是一个全高模块，提供四个继电器产出。任何数量的继电器模块可以放置在任何机架接口模块右侧的插槽。4通道的每个输出继电器模块可以独立编程，以执行所需的表决逻辑。

4通道继电器模块上使用的每个继电器都包括“报警驱动逻辑”。

报警驱动逻辑使用“与”和“或”逻辑进行编程，并可利用来自任何监控通道或任何机架中监视器通道的组合。该警报驱动逻辑

编程使用3500框架配置软件来满足特定的应用程序的需求。

注意:三模冗余(TMR)应用需要使用133323-O1TMR继电器模块。

BENTELY 133323-01 通讯网关4通道继电器模块

Product Introduction:

The 4-channel relay module is a full height module that provides four relay outputs. Any number of relay modules can be placed in the slot on the right side of any rack interface module. Each of the 4-channel output relay modules can be programmed independently to perform the required voting logic.

Each relay used on the 4-channel relay module includes "alarm drive logic".

The alarm driver logic is programmed using "and" and "or" logic and can be used from a combination of any monitor channel or monitor channel in any rack. The alert drives the logic

Programming uses the 3500 framework to configure software to meet the needs of specific applications.

Note: Three-mode redundancy (TMR) applications require the use of the 133323-O1TMR relay module.
