3500/45 通道位置监视器 是用于机械状态监测的

3500/45 通道位置监视器 是用于机械状态监测的

零件编号：3500/45
制造商：Bently Nevada
系列：3500/45
产品类型：位置监测器
工作温度：-30°C 至 +65°C
可用性：有库存
原产地：美国 (USA)

3500/45 是 Bently Nevada 制造的位置监测器，是用于机械状态监测的 3500/45 系列的一部分。它是一种四通道设备，可从接近传感器、旋转位置传感器 (RPT)、直流线性可变差动变压器 (DC LVDT)、交流线性可变差动变压器 (AC LVDT) 和旋转电位计获取数据。监测器对信号进行预处理并将其与用户可编程的警报进行比较。

应用
3500 机架配置软件允许您对每个通道进行编程以完成以下任务：

轴向（推力）位置
差别扩张
标准单斜坡差动膨胀
非标单斜坡差动膨胀
双斜坡差异扩张
互补差异扩张
案例扩展
阀门位置
3500/45 位置监视器的主要功能是提供以下功能：

通过将观察到的参数与预定义的警报设置点实时比较以触发警报来保护机器
运维人员需要了解的机器信息
根据设计，每个通道通常会调节其输入信号以产生一组可测量的变量。可以为任何活动测量变量设置警报设置点，也可以为任意两个活动测量变量设置危险设置点。

3500/45 通道位置监视器 是用于机械状态监测的

Part Number: 3500/45
Manufacturer: Bently Nevada
Series: 3500/45
Product Type: Position monitor
Operating temperature: -30°C to +65°C
Availability: Available in stock
Country of Origin: USA (USA)

The 3500/45 is a position monitor manufactured by Bently Nevada and is part of the 3500/45 family for mechanical condition monitoring. It is a four-channel device that draws data from proximity sensors, rotary position sensors (RPT), DC linear variable differential transformers (DC LVDT), AC linear variable differential transformers (AC LVDT), and rotary potentiometers. The monitor preprocesses the signal and compares it to a user-programmable alarm.

Apply
The 3500 rack configuration software allows you to program each channel to accomplish the following tasks:

Axial (thrust) position
Differential extension
Standard single-slope differential expansion
Non-standard single slope differential expansion
Double slope differential expansion
Complementary differential expansion
Case extension
Valve position
The main function of the 3500/45 position monitor is to provide the following functions:

Protect the machine by comparing observed parameters to predefined alarm setting points in real time to trigger alarms
Machine information that operation and maintenance personnel need to know
By design, each channel typically adjusts its input signal to produce a set of measurable variables. You can set an alert setting point for any active measurement variable, and you can set a danger setting point for any two active measurement variables.

3500/45 通道位置监视器 是用于机械状态监测的
