与一般的数控系统不同，发那科系统采用自己独特的供电系统进行供电，有的书叫功放，有的书直接叫电源模块。

电源模块作为独立模块安装在机床的电气柜中。今天简单介绍一下电源模块的接线。给电源模块面板贴上标签如下:然后逐—浏览各个界面:(1)-TB<>:直流电源的输出端子

接口与主轴放大器和伺服放大器的直流输入端连接，为主轴放大器和伺服放大器提供DC300V电源。

(2)一状态指示
LED用于指示电源模块的状态，出现异常时显示相关报警代码。
(1) —CX<>A
单相AC200V输入接口。
(1)—CX<>B
单相200VAC输出接口。
(5)–直流电路连接点状态指示
只有在指示灯完全熄灭后，才能对模块电缆进行各种操作，否则很危险。

A06B-1475-B123#0321 FANUC交流伺服电机

Different from the general numerical control system, Fanuc system uses its own unique power supply system for power supply, some books are called power amplifier, and some books are directly called power module.

The power module is installed as an independent module in the electrical cabinet of the machine tool. Today, we briefly introduce the wiring of the power module. Label the power module panel as follows: Then - View each screen :(1)-TB<>: Output terminal of the DC power supply

The interface is connected to the DC input of the spindle amplifier and servo amplifier to provide DC300V power supply for the spindle amplifier and servo amplifier.

(2) A status indication
LED is used to indicate the status of the power module and display the relevant alarm code when there is an anomaly.
(1) —CX<>A
Single-phase AC200V input interface.
(1)—CX<>B
Single phase 200VAC output interface.
(5) - direct current connection point status indication
Only after the indicator light is completely off, can you perform various operations on the module cable, otherwise it is dangerous.
