伺服放大器模块 A06B6121H030#H550 是 Fanuc 为 αi SP 系列制造的 αi SPM-30HVI 模块，作为 1 个伺服传感器输入单元。αi SP 是 αi SP 系列中的两种类型之一。

两种类型是 200V 输入系列和 400V 输入系列。200V 系列驱动 200V 输入系列的伺服电机。400V 输入系列驱动 400V 输入系列的伺服电机。Fanuc A06B6121H030#H550 是一款支持 400V 输入的放大器。

A06B6121H030#H550的特点

CNC Fanuc 伺服放大器 A06B6121H030#H550 模块是三相 400 CAC 至 480 VAC 主电源单元。αi SPM-30HVI 的额定输出为 170 A，可与 αi I 60HV 电机配合使用。本机适用的 CNC 有 16i-B、18i-B、21i-B、0i-B/C/D 和 30i/31i/32i。A06B6121H030#H550 的速度控制范围为速比 1：100。速度变化率为zui大速度的0.1%或更低。它具有 -15% 至 +10% 的允许电压偏差。A06B6121H030#H550 αi SPM-30HVI 的电源频率为 50/60Hz，±1Hz。设备应在 0 至 55°C 的环境温度下运行。 设备运行时的湿度应为 90% RH 或以下，振动应低于 0.5 G。

A06B-6121-H030-#H550 主轴放大器 带晶体管的正弦波PWM控制

The servo amplifier module A06B6121H030#H550 is an αi SPM-30HVI module manufactured by Fanuc for the αi SP series as a servo sensor input unit. Alpha i SP is one of the two types in the alpha i SP family.

The two types are 200V input series and 400V input series. 200V series Drive 200V input series servo motor. 400V Input series Drive 400V input series servo motor. The Fanuc A06B6121H030#H550 is an amplifier that supports 400V inputs.

A06B6121H030#H550 features

CNC Fanuc Servo Amplifier A06B6121H030#H550 module is a three-phase 400 CAC to 480 VAC main power supply unit. The αi SPM-30HVI has A rated output of 170 A and can be used with the αi 60HV motor. The CNC for this machine is 16i-B, 18i-B, 21i-B, 0i-B/C/D and 30i/31i/32i. The A06B6121H030#H550 has a speed control range of 1:100. The speed change rate is 0.1% or less of the maximum speed. It has an allowable voltage deviation of -15% to +10%. A06B6121H030# H550αi SPM-30HVI has a power supply frequency of 50/60Hz, ±1Hz. The equipment should be operated at an ambient temperature of 0 to 55°C. The humidity of the equipment should be 90% RH or less, and the vibration should be less than 0.5 G.
