A6500-SR 16通道继电器输出模块

A6500-SR 16通道继电器输出模块

A6500-SR 系统框架是 CSI 6500 ATG 机械保护系统的一部分。它是 19 ” 的框架结构(84HP 宽，3RU 高 )。A6500-SR 系统框架能够安装 11 块保护卡件 (2 通道 A6500-UM 通用测量卡和 / 或者 4 通道 A6500-TP 温度过程量卡 )，1 块 A6500-RC 继电器卡，和块 A6500-CC 通讯卡 — 2 块用于冗余通讯的通讯卡。
A6500-SR 系统框架的背板使用了压入式弹簧连接端子，用于接入输入和输出信号，传感器的原始信号使用 D-sub 接口输出，拨码开关用于设置键相信号和二进制输入。
11 块用于保护的卡件均有 4 个 8 孔的压入式弹簧连接端子用于连接不同种类的传感器(电涡流传感器，压电式传感器，地震式传感器，热电阻等等)，二进制输入，二进制输出(功能输出 )，电流输出和脉冲输出。可使用的测量通道数和所有的其它功能都取决于安装的卡件您可以使用第二个系统框架将当前的系统扩展成 6RU 的系统。这种情况下，第 一个框架上的通讯卡将被这 2 个框架同时使用

A6500-SR 16通道继电器输出模块

The A6500-SR system framework is part of the CSI 6500 ATG Mechanical protection System. It is 19 "frame construction (84HP wide, 3RU high). The A6500-SR system frame is capable of mounting 11 protective cards (2-channel A6500-UM universal measuring card and/or 4-channel A6500-TP Temperature process card), 1 A6500-RC relay card, and 1 A6500-RC relay card. A6500-CC communication card - Two communication cards for redundant communication.
The backplane of the A6500-SR system frame uses push-in spring connection terminals for input and output signals, the raw signal of the sensor is output using the D-sub interface, and the dip switch is used to set the key trust signal and binary input.
Each of the 11 protective tabs has 4 8-hole press-in spring connection terminals for connecting different types of sensors (vortex current sensors, piezoelectric sensors, seismic sensors, thermal resistors, etc.), binary input, binary output (functional output), current output and pulse output. The number of measurement channels available and all other functions depend on the installed cards. You can use the second system framework to extend the current system into a 6RU system. In this case, the communication card on the first framework will be used by both frameworks

A6500-SR 16通道继电器输出模块
