Allen-Bradley 1756-OW16I是十六(16)通道离散输出模块，是ControlLogix自动化平台的一部分。该模块是一个继电器输出模块，触点形式为常开(N.O .)，带有独立隔离。该模块也可称为干触点输出模块，可兼容在5-125VDC和10-240VAC的电压范围内运行。

1756-OW16I在5-30V DC时输出电流额定值为1a；48伏直流电时为0.5安；125伏直流电时为0.22安；120伏交流电时为1.5安，50/60赫兹，240伏交流电时为0.75安，50/60赫兹。该模块的先导占空比为C300/R150。

对于两种信号转换，每个输出通道的zui大输出延迟时间为10 ms。在5.1 VDC和24VDC下，它从背板汲取150 mA电流，总背板功耗为4.4瓦。

1756-OW16I ControlLogix离散输出模块

Allen-Bradley 1756-OW16I is a sixteen (16) channel discrete output module that is part of the ControlLogix automation platform. The module is a relay output module, the contact form is normally open (N.O.) , with separate isolation. The module can also be referred to as the dry contact output module and is compatible to operate in the voltage range of 5-125VDC and 10-240VAC.

1756-OW16I output current rating is 1a at 5-30V DC; 0.5 amps at 48 volts DC; 0.22 a at 125 volts DC; 1.5 amps at 50/60 Hertz at 120 volts AC and 0.75 amps at 50/60 Hertz at 240 volts AC. The module has a lead duty cycle of C300/R150.

For both signal conversions, the maximum output delay time for each output channel is 10 ms. At 5.1 VDC and 24VDC, it draws 150 mA of current from the backplane for a total backplane power consumption of 4.4 watts.
