ACC-5595-208 GE 通用电气 网络集线器

ACC-5595-208 GE 通用电气 网络集线器

特性
l 1 到 8 口可配置SFP收发器

l 大可级联256个节点

l 自动旁路故障节点

l 自动旁路模式可选

l 配置可选节点传输距离达10公里

l 可插拔收发器支持单模或者多模模式

l 1x8 口或者2x4 口

l 可以通过串口了解状态进行设置

概述
GE反射内存交换机（以下简称交换机）是为GE系列通信网络而设计，当交换机检测到板卡信号丢失时可以自动旁路未启动或故障的节点，允许其他GE系列通信网络节点卡继续操作。GE反射内存交换机有8个SFP收发器，在短距离通信时可以使用多模收发器，远距离时可以使用单模收发器。GE反射内存交换机可以级联以组成更大的网络。通过232接口可以查看信息，配置交换机。

ACC-5595-208 GE 通用电气 网络集线器

peculiarity
l 1 to 8 ports configurable SFP transceivers

Up to 256 nodes can be cascaded

l Automatically bypass the faulty node

l Automatic bypass mode Optional

l Optional node transmission distance up to 10 km

l Pluggable transceiver supports single mode or multi-mode mode

l 1x8 or 2x4

l You can know the status through the serial port to set

summarize
GE reflective memory switches (switches for short) are designed for GE series communication networks. When a switch detects a signal loss on a board, it can automatically bypass an unstarted or faulty node, allowing other GE series communication network node cards to continue operating. GE reflective memory switches have eight SFP transceivers, allowing for multi-mode transceivers for short distance communication and single-mode transceivers for long distance communication. GE reflective memory switches can be cascaded to form larger networks. The 232 interface allows you to view information and configure switches.

ACC-5595-208 GE 通用电气 网络集线器
