AI620 模拟量输出模块 ABB 采用高性能的处理器

AI523 1SAP250300R0001 ABB 模拟输入模块

详细说明:AI523: S500模拟输入模块。16 ai: u, i, r, d, i。机的。

-40°c…+ 70°C
-40°c…-30℃:系统正常启动;技术数据不保证
-40°c…0°C:由于LCD技术
显示响应可能非常慢。
-40°c…+40℃:模块垂直安装
可能，输出负载限制在每组50%
+60°c…+70°C，降额如下:
●系统限制为zui大。每个终端底座2个通信模块
●数字输入:同时打开输入通道的zui大数量限制为每组75%(例如8通道=> 6通道)
●数字输出:输出电流zui大值(所有通道一起)限制为每组75%(例如8 A => 6 A)
●模拟输出仅当配置为电压输出时:每组zui大总输出电流限制为75%(例如40 mA => 30 mA)
●模拟输出仅当配置为电流输出时:zui大同时使用的输出通道数量限制为每组75%(例如4通道=> 3通道)

AI620 模拟量输出模块 ABB 采用高性能的处理器

Description :AI523: S500 analog input module. 16 ai: u, i, r, d, i. Legitimate.

-40°c… + 70°C
-40°c… -30 ° C: The system starts normally. Technical data is not guaranteed
-40°c… 0°C: Due to LCD technology
Display response can be very slow.
-40°c… +40 ° C: The module is installed vertically
Possible, the output load is limited to 50% per group
+60°c… +70°C, the derating is as follows:
● The system limit is maximum. Two communication modules per terminal base
● Digital input: The maximum number of input channels open at the same time is limited to 75% per group (e.g. 8 channels => 6 channels)
● Digital output: Maximum output current (all channels together) is limited to 75% per group (e.g. 8 A => 6 A)
● Analog output only when configured as a voltage output: maximum total output current limit of 75% per group (e.g. 40 mA => 30 mA)
● Analog output only when configured as a current output: The maximum number of output channels used at the same time is limited to 75% per group (e.g. 4 channels => 3 channels)

AI523 1SAP250300R0001 ABB 模拟输入模块
