S21260-SRS DANAHER 高性能紧凑型无刷伺服驱动器

S21260-SRS DANAHER 高性能紧凑型无刷伺服驱动器

产品描述

S21260-SRS DANAHER高性能紧凑型无刷伺服驱动器旨在控制和驱动无刷伺服电机。

特征

紧凑型设计

高性能控制

无刷电机兼容性

多功能输入和输出选项

先进的运动控制算法

S21260-SRS DANAHER是一 流的伺服驱动器，具有卓越的性能和可靠性。凭借其紧凑的尺寸和先进的功能，它为广泛的应用提供了精 确的控制和高效的操作。

Danaher Motion的S21260-SRS无刷伺服驱动器将高性能伺服技术纳入一个全功率范围的系列，包括直流输入和交流输入系列成员。特别是对于低功耗应用，S200系列提供了比以前更高性能、更稳健的选择，而不必在可靠性或封装尺寸上妥协。将S200驱动器与Danaher Motion的AKM伺服电机相结合，提供了一个完整的伺服控制解决方案，专为半导体制造、电子组装、包装、医疗和木工设备等应用而设计。

Danaher Motion的S21260-SRS伺服驱动器是第 一款速度环路带宽高达800Hz的全数字工业驱动器，提供无与伦比的系统吞吐量和简化的调谐。高分辨率（24位）反馈和高性能3-5 kHz电流环路带宽提供平稳的运动和快速的启动和停止动作，以优化机器性能。智能反馈和业界领 先的高带宽消除了大多数应用中对伺服回路调谐的需求，从而提供快速准确的“即插即用”调试。Base S21260-SRS伺服驱动器标配扭矩或速度控制，以及支持SynqNet运动网络的出厂选项，或通过CANopen通信添加可预先设置的索引。工厂选项卡还为其他电机反馈设备添加了接口，如Comcoder、1 Vp-p Sin Cos、EnDat 2.1和EnDat 2.2，它们在2.1兼容模式下运行。选项卡EnDat接口可容纳单圈和多圈绝 对旋转或增量和绝 对线性编码器。驱动器使用AC（120/240 VAC）或DC（20-90 VDC）电源运行，额定电流从1.5ARMS连续到48 ARMS峰值。它们紧凑的占地面积从1.1英寸（28.7毫米）宽和6.0英寸（152.4毫米）高到3.8英寸（94.6毫米）宽，6.39英寸（213毫米）高，深度从3.9英寸（100.8毫米）到7.57英寸（192.4毫米），使它们能够适应狭小的空间。它们经过UL 508C认证，CE认证，符合EN50178和EN61800-3标准。zui初的S200系列在焊接中包含了铅。

应用领域

S21260-SRS DANAHER伺服驱动器适用于机器人、数控机床、包装设备和其他高性能运动控制系统。

S21260-SRS DANAHER 高性能紧凑型无刷伺服驱动器

Product description

The S21260-SRS DANAHER high-performance compact brushless servo drive is designed to control and drive brushless servo motors.

trait

Compact design

High performance control

Brushless motor compatibility

Multifunctional input and output options

Advanced motion control algorithm

The S21260-SRS DANAHER is a first-class servo drive with superior performance and reliability. With its compact size and advanced features, it provides precise control and efficient operation for a wide range of applications.

Danaher Motion's S21260-SRS brushless servo drives incorporate high-performance servo technology into a full power range family, including DC input and AC input family members. Especially for low-power applications, the S200 series offers higher performance and more robust options than before, without having to compromise on reliability or package size. Combining the S200 drive with Danaher Motion's AKM servo motors provides a complete servo control solution designed for applications such as semiconductor manufacturing, electronics assembly, packaging, medical and woodworking equipment.

Danaher Motion's S21260-SRS servo driver is the first fully digital industrial driver with speed loop bandwidth up to 800Hz, providing unmatched system throughput and simplified tuning. High resolution (24-bit) feedback and high performance 3-5 kHz current loop bandwidth provide smooth motion and fast start and stop actions to optimize machine performance. Intelligent feedback and industry-leading high bandwidth eliminate the need for servo loop tuning in most applications, providing fast and accurate "plug and play" debugging. The Base S21260-SRS servo drivers come standard with torque or speed control, as well as factory options to support SynqNet motion networks, or to add pre-set indexes via CANopen communication. The Factory TAB also adds interfaces for other motor feedback devices such as Comcoder, 1 Vp-p Sin Cos, EnDat 2.1 and EnDat 2.2, which operate in 2.1 compatibility mode. The TAB EnDat interface can accommodate single and multi-turn absolute rotation or incremental and absolute linear encoders. The drive operates with AC (120/240 VAC) or DC (20-90 VDC) power, rated from 1.5ARMS continuous to 48 ARMS peak. Their compact footprint ranges from 1.1 inches (28.7 mm) wide and 6.0 inches (152.4 mm) high to 3.8 inches (94.6 mm) wide, 6.39 inches (213 mm) high, and depths from 3.9 inches (100.8 mm) to 7.57 inches (192.4 mm), allowing them to fit in tight Spaces. They are UL 508C certified, CE certified and comply with EN50178 and EN61800-3 standards. The original S200 series included lead in the welds.

Application field

The S21260-SRS DANAHER servo drive is suitable for robots, CNC machine tools, packaging equipment and other high-performance motion control systems.
