CX11000001 BECKHOFF 以太网模块 CPU识别和处理的有效数据

CX11000001 BECKHOFF 以太网模块 CPU识别和处理的有效数据

以太网模块的主要作用就是对以太网上的传输信号进行调试和解调试,把信号转换成可以让CPU识别和处理的有效数据的模块。以太网上的数据是以一种差分的形式传递的。处理器无法识读。所以需要以太网模块，将网络线上

的信号转换为CPU能够识别的0和1这样的数据。同时有些以太网模块也按照TCP/IP协议,将网络上传递的数据进行转换。

以太网模块的功能 随着物联网行业的不断发展，生产以太网模块的厂家也越来越多，不同的以太网模块功能也有所不同，由成都众山生产的ZS-Ethernet-801嵌入式以太网模块，采用工业级设计，拥有超小，支持TCP/UDP协议双向透明传输，TTL串口转以太网通讯，采用高品质元器件配置。

CX11000001 BECKHOFF 以太网模块 CPU识别和处理的有效数据

The main function of the Ethernet module is to debug and debug the transmitted signal on the Ethernet network, and convert the signal into a module that can allow the CPU to recognize and process effective data. Data on the Ethernet is transmitted in a differential form. The processor can't read it. So an Ethernet module is needed to bring the network online

The signal is converted into data such as 0 and 1 that the CPU can recognize. At the same time, some Ethernet modules also convert the data transmitted on the network according to the TCP/IP protocol.

With the continuous development of the Internet of Things industry, there are more and more manufacturers producing Ethernet modules, and different Ethernet modules have different functions. The ZS-Ethernet-801 embedded Ethernet module produced by Chengdu Zhongshan adopts industrial design, has ultra-small, and supports two-way transparent transmission of TCP/UDP protocol. TTL serial to Ethernet communication, using high-quality components configuration.

CX11000001 BECKHOFF 以太网模块 CPU识别和处理的有效数据
