产品描述
通用电气紧急超速板型号DS200TCEAG1B具有一个微处理器和多个可编程只读存储器 （PROM） 模块。它还包含 3 个保险丝、30 个跳线和一对卡口连接器。该板监控变频器的超速和火焰检测跳闸情况，并根据需要关闭变频器。卡口连接器用于将主板连接到驱动器中的其他设备和主板。在将电缆末端的公卡口连接器连接到板上的母连接器之前，需要考虑一些因素。要卸下卡口连接器，请用一只手握住连接器，另一只手固定电路板以防止其弯曲或移动。将卡口连接器从板上的母连接器中拉出，然后将电缆放在一边，直到您准备好将其连接到更换板。

一个警告是，您不能通过拉扯电缆而不是连接器来断开卡口连接器。这可能会将信号线从卡口连接器中拉出，从而损坏电缆。此外，请勿使用卡口连接器意外接触电路板上的其他组件。您可能会弯曲或划伤组件或电路板的表面。

要连接卡口连接器，请对齐连接器并将其压入板上的连接器中。当它完全安装时，它会卡入到位。作为测试连接的一种手段，您可以轻轻拉扯电缆。

DS200TCEAG1BNE 紧急超速板 具有一个微处理器

Product description
The GE Emergency Overdrive board model DS200TCEAG1B has a microprocessor and multiple programmable read-only memory (PROM) modules. It also contains 3 fuses, 30 jumpers and a pair of bayonet connectors. The board monitors the frequency converter for overspeed and flame detection tripping and shuts down the frequency converter as needed. Bayonet connectors are used to connect the motherboard to other devices and motherboards in the drive. There are several factors to consider before connecting the male bayonet connector at the end of the cable to the female connector on the board. To remove the bayonet connector, hold the connector with one hand and secure the board with the other to prevent it from bending or moving. Pull the bayonet connector out of the female connector on the board, then set the cable aside until you are ready to connect it to the replacement board.

One caveat is that you cannot disconnect the bayonet connector by pulling on the cable instead of the connector. This can pull the signal wire out of the bayonet connector, damaging the cable. In addition, do not use bayonet connectors to accidentally touch other components on the board. You may bend or scratch the surface of a component or circuit board.

To connect bayonet connectors, align the connector and press it into the connector on the board. When it is fully installed, it snaps into place. As a means of testing the connection, you can gently pull on the cable.
