DS200TCRAG1ACC 继电器输出板 装有30个插入式继电器

DS200TCRAG1ACC 继电器输出板 装有30个插入式继电器

产品描述
GE继电器输出板DS200TCRAG1ACC装有30个插入式继电器。它还具有 4 个 34 针连接器和 4 个 12 针连接器。分配给 34 针连接器的 ID 是 JOR、JOS、JOT 和 JO。分配给 12 针连接器的 ID 为 JS3、JS4、JS5 和 JS6。由于 GE 继电器输出板上有多个连接器DS200TCRAG1ACC，因此必须遵循准则，以确保您可以快速将电缆连接到更换板上的正确连接器。在开始更换之前，请确保您知道提供给驱动器的电流的紧急关闭装置的位置。而且，您必须了解如何操作关闭装置并验证其是否处于良好的工作状态。熟悉变频器安装的人员将获得有关电源和紧急切断的详细信息。下一步是验证驱动器周围区域的地板是否干净且没有湿气或积水。使用清洁剂清洁地板上的油或油脂。您还应该拔下所有未接地的两相电源线，因为有触电的危险。

zui佳做法是通知工作区中其他设备的操作员和管理人员已安排工作，以便他们可以计划工作中断并围绕它进行计划。在驱动器附近选择一个清晰、平坦且坚固的工作空间，并将装有电路板的盒子放在上面。

DS200TCRAG1ACC 继电器输出板 装有30个插入式继电器

Product description
The GE relay output board DS200TCRAG1ACC contains 30 plug-in relays. It also features four 34-pin connectors and four 12-pin connectors. The ids assigned to the 34-pin connector are JOR, JOS, JOT, and JO. The ids assigned to 12-pin connectors are JS3, JS4, JS5, and JS6. Because there are multiple connectors DS200TCRAG1ACC on the GE relay output board, guidelines must be followed to ensure that you can quickly connect the cable to the correct connector on the replacement board. Before starting the replacement, make sure you know the location of the emergency shut-off device for the current supplied to the drive. Moreover, you must know how to operate the shutdown device and verify that it is in good working order. Those who are familiar with the installation of frequency converters will receive detailed information on power supply and emergency cut-off. The next step is to verify that the floor in the area around the drive is clean and free of moisture or standing water. Use a cleaner to clean oil or grease from the floor. You should also unplug all ungrounded two-phase power cords, as there is a risk of electric shock.

The best practice is to notify operators and managers of other devices in the workspace that work is scheduled so that they can plan for work disruptions and plan around it. Choose a clear, flat, and sturdy workspace near the drive and place the box with the circuit board on it.
