IC200MDL640M 分立式输入模块 Versamax 正/负逻辑输入模块
IC200MDL640 分立式输入模块是 GE Fanuc 24 伏直流正/负逻辑输入模块，在 Versamax 系列中具有 16 个输入点。16 个输入分为 2 组。输入可以具有正逻辑或负逻辑。正输入接收来自输入器件的电流，负输入接收电流至输入器件。输入设备可以连接在公共端子和输入端子之间。背板提供模块运行所需的电源。5 V 输出时的背板电流消耗额定值zui大为 25 毫安。IC200MDL640 离散输入模块具有 CPU 或 NIU 来执行其处理功能。
IC200MDL640 离散输入模块的每个点有 1 个 LED 指示灯。它不需要任何热降额或外部电源。模块的输入响应时间是一个可配置的参数，可以很容易地进行配置。可配置的过滤时间包括zui小 0 毫秒、默认值 1.0 毫秒和zui长 7.0 毫秒。模块的输入电压为 0 至 30 伏直流电和 24 伏直流电标称值。
它带有 15 至 30 伏直流的导通状态电压和 0 至 5 伏直流的关断状态电压。输入的基本开/关响应时间为 0.5 毫秒。建议用户在现场接线时使用带有 B 端子的短路条来布置额外的总线端子。IC200MDL640 分立输入模块支持热插入。但是，在安装过程中必须格外小心，以避免背板中断。
IC200MDL640M 分立式输入模块 Versamax 正/负逻辑输入模块
The IC200MDL640 split input module is a GE Fanuc 24-volt DC positive/negative logic input module with 16 input points in the Versamax family. The 16 inputs are divided into 2 groups. The input can have positive or negative logic. The positive input receives the current from the input device, and the negative input receives the current to the input device. The input device can be connected between the common terminal and the input terminal. The midplane supplies power for module operation. The backplane current consumption rating at 5 V output is up to 25 mA. The IC200MDL640 discrete input module has a CPU or NIU to perform its processing functions.
The IC200MDL640 discrete input module has 1 LED indicator at each point. It does not require any heat derating or external power supply. The input response time of a module is a configurable parameter that can be easily configured. Configurable filtering times include a minimum of 0 ms, a default of 1.0 ms, and a maximum of 7.0 ms. The input voltage of the module is 0 to 30 VDC and the nominal value of 24 VDC.
It comes with an on-state voltage of 15 to 30 volts DC and a off state voltage of 0 to 5 volts DC. The input has a basic on/off response time of 0.5 ms. It is recommended that you use a short circuit bar with B terminal to lay out additional bus terminals during field wiring. The IC200MDL640 discrete input module supports hot insertion. However, extra care must be taken during installation to avoid backplane disruption.
IC200MDL640M 分立式输入模块 Versamax 正/负逻辑输入模块
