VersaMax IC200PWR002是通用电气发那科公司生产的扩展电源模块。该模块的工作是为以下类型的背板设备供电:cpu, niu, I/O模块等。当连接到中央处理单元或网络接口单元时，该电源模块作为主电源，但也可以安装在升压载体上作为辅助电源。

IC200PWR002采用直流输入和输出电压。本设备的输入电压可以在18伏到30伏之间变化。标称输入电压为直流24伏。该电源单元的输入功率为11瓦，在24伏和30伏直流时，浪涌电流分别额定为20安培和25安培。该模块的保持时间约为10毫秒。

IC200PWR002的输出电压为3.3伏直流电和5伏直流电，输出电流由3.3伏和5伏输出电压组合决定;但是，输出电流不应超过1.5安培。

IC200PWR002具有短路、过载和反极性保护选项。现场接线时，请确保直流接地与机架接地和接地。注意:直流-从电源单元本身内部接地到机架。因此，浮动电源配置是不可能的。

IC200PWR002D 自动化控制 工控配件

The VersaMax IC200PWR002 is an expansion power module manufactured by General Electric Fanuc. The module's job is to power the following types of backplane devices :cpu, niu, I/O modules, etc. When connected to a central processing unit or network interface unit, the power module acts as a primary power supply, but can also be mounted on a booster carrier as an auxiliary power supply.

The IC200PWR002 uses DC input and output voltages. The input voltage of this device can vary between 18 volts and 30 volts. The nominal input voltage is 24 volts DC. The power supply unit has an input power of 11 watts and an inrush current rating of 20 amps and 25 amps respectively at 24 volts and 30 volts DC. The module's hold time is about 10 milliseconds.

The output voltage of IC200PWR002 is 3.3 volts DC and 5 volts DC, and the output current is determined by the combination of 3.3 volts and 5 volts output voltage. However, the output current should not exceed 1.5 amps.

The IC200PWR002 has options for short circuit, overload and reverse polarity protection. When connecting cables onsite, ensure that the DC ground is grounded to the rack. Note: DC - Ground from inside the power unit itself to the rack. Therefore, floating power configuration is not possible.
