IC693CPU351-HT 单插槽模块化CPU 2048 个离散输出

IC693CPU351-HT 单插槽模块化CPU 2048 个离散输出

目录号为 IC693CPU351 的 GE Fanuc 90-30 模块是模块化 CPU 子类别的一部分。该 CPU 专为需要更高复杂性、更快处理速度和支持大量 I/O 的应用而设计。该模块是单插槽 CPU 模块，设计用于安装在 5 插槽或 10 插槽 CPU 底板上。

IC693CPU351支持大量 I/O，特别是 2048 个离散输入点 （%I）;2048 个离散输出点 （%Q） 和模拟 I/O 字，因所使用的软件而异，但zui大可配置的模拟 I/O 为 32、640 个字。此 CPU 可用的其他内部寄存器数量是 1280 位二进制全局存储器;4096位存储线圈;256位临时输出线圈;128 位系统状态参考;zui多 32640 字的寄存器存储器和 28000 字的系统寄存器，仅可用于参考表查看。

该模块化 CPU 可配置为在 I/O 扩展或远程 I/O 底板之间进行通信和执行 I/O 数据交换。具体来说，七 （7） 个和/或 I/O 扩展或远程 I.O 基板。为了与人机界面 （HMI） 或监控和数据采集系统 （SCADA） 等可视化系统和其他自动化设备进行通信，IC693CPU351 配有三 （3） 个串行端口。一 （1） 个串行端口位于支持 SNP/SNPX 从站的电源连接器上，而端口 1 和 2 支持 RTU 从站、SNP/SNPX 主/从协议。该模块化 CPU 还支持通信模块的安装。

GE Fanuc IC693CPU351 CPU是一个模块化的CPU模块。IC693CPU351 CPU 专为 90-30 系列可编程逻辑控制器 （PLC） 系统而开发。CPU 的时钟速度为 25 兆赫兹。处理器类型是 80386EX 处理器。IC693CPU351 CPU 是 GE350 至 364 CPU 系列的一部分，该系列旨在满足需要更快处理速度、更大内存容量的客户需求。IC693CPU351 CPU 由 Logicmaster 90-30、6.0 版及更高版本的微编程和配置软件以及 2.0 版及更高版本的控制编程和配置软件提供支持。IC693CPU351 CPU 上的用户内存为 240 KB（受 9.0 及更高版本的 CPU 固件支持）。对于 9.0 版之前的固件，CPU 模块内存大小为 80 KB。

IC693CPU351 CPU 不支持嵌入式以太网端口，但 CPU 模块上有 3 个内置串行端口。可用于 IC693CPU351 CPU 的可选通信模块包括 Profibus、GBC、以太网、GCM 和 GCM+ 模块。IC693CPU351 CPU 支持浮点数学函数。IC693CPU351 CPU 上还提供了一个按键开关。该模块上还提供顺序事件记录器。模块上的内部线圈额定值为 4096 位，输出（临时）线圈的额定值为 256 位。IC693CPU351 CPU 的电源要求是 5 伏直流电压和 890 毫安电流。电池备份时钟和覆盖在IC693CPU351 CPU 上可用。工作温度范围为 32 至 140 华氏度。

IC693CPU351-HT 单插槽模块化CPU 2048 个离散输出

The GE Fanuc 90-30 module with directory number IC693CPU351 is part of the modular CPU subclass. The CPU is designed for applications that require higher complexity, faster processing speed, and support for large amounts of I/O. The module is a single-slot CPU module designed to be mounted on a 5 - or 10-slot CPU baseboard.

The IC693CPU351 supports a large number of I/ OS, especially 2048 discrete input points (%I). 2048 discrete output points (%Q) and analog I/O words, depending on the software used, but the maximum configurable analog I/O is 32, 640 words. The number of other internal registers available for this CPU is 1280-bit binary global memory; 4096-bit storage coil; 256-bit temporary output coil; 128-bit system status reference; Register memory of up to 32,640 words and system registers of 28,000 words are available for reference table viewing only.

The modular CPU can be configured to communicate and perform I/O data exchange between I/O expansions or remote I/O backboards. Specifically, seven (7) and/or I/O extensions or remote I.O baseboards. For communication with visualization systems such as Human Machine Interface (HMI) or Supervisory Control and Data Acquisition System (SCADA) and other automation devices, the IC693CPU351 is equipped with three (3) serial ports. One (1) serial port is located on a power connector that supports SNP/SNPX slave stations, while ports 1 and 2 support RTU slave stations and SNP/SNPX master/slave protocols. The modular CPU also supports the installation of communication modules.

The GE Fanuc IC693CPU351 CPU is a modular CPU module. The IC693CPU351 CPU was developed for the 90-30 series Programmable Logic controller (PLC) system. The CPU has a clock speed of 25 megahertz. The processor type is 80386EX processor. The IC693CPU351 CPU is part of the GE350 to 364 CPU family, which is designed to meet customer needs for faster processing speed and greater memory capacity. The IC693CPU351 CPU is supported by Logicmaster microprogramming and configuration software versions 90-30, 6.0 and higher, and control programming and configuration software versions 2.0 and higher. The user memory on the IC693CPU351 CPU is 240 KB (supported by CPU firmware 9.0 and later). For firmware before version 9.0, the CPU module memory size is 80 KB.

The IC693CPU351 CPU does not support an embedded Ethernet port, but there are three built-in serial ports on the CPU module. Optional communication modules available for the IC693CPU351 CPU include Profibus, GBC, Ethernet, GCM, and GCM+ modules. The IC693CPU351 CPU supports floating point math functions. The IC693CPU351 CPU also provides a key switch. A sequential event logger is also available on this module. The internal coil on the module is rated at 4096 bits and the output (temporary) coil is rated at 256 bits. The power supply requirements for the IC693CPU351 CPU are 5 volts DC and 890 mA. The battery backup clock and overlay are available on the IC693CPU351 CPU. Operating temperature range is 32 to 140 degrees Fahrenheit.
