IC694ALG233输入模块是模拟电流输入模块。该输入模块提供 16 个单端输入通道。安装在危险场所时，必须先关闭IC694ALG233输入模块的电源，然后才能更换或接线。此外，除非主系统电源已关闭，否则不应将模块连接到 PLC 或与 PLC 断开。IC694ALG233输入模块从系统背板上的 +5 V 直流母线汲取 120 毫安的电流。除环路电流外，IC694ALG233输入模块还从 24 V 直流额定外部电源汲取 65 毫安的电流。IC694ALG233输入模块可以承受的外部电压电源纹波为 10%。外部电源的电压范围为 20 至 30 伏直流电。额定输入低通滤波器响应为 23 赫兹

IC694ALG233 输入模块上共有 16 个通道，每个通道可以配置以下输入范围：0 至 20 毫安、4 至 20 毫安增强和 4 至 20 毫安正常。报警上限和下限也可以通过软件进行配置。对于 4 至 20 毫安的增强电流范围，可以配置一个较低的报警限值，以检测 4 至 20 毫安之间的输入电流。此功能可用于在 4 至 20 毫安的增强额定电流应用中提供断线检测。IC694ALG233输入模块还使用分配的程序参考地址向系统 CPU 报告模块状态和外部电源状态。IC694ALG233输入模块可以安装在带有串行连接器的 I/O 插槽中。IC694ALG233输入模块支持热拔插。IC694ALG233输入模块上的固件可以升级以启用新功能。

IC694ALG233 是一个模拟电流输入模块 有 16 个输入通道

The IC694ALG233 input module is an analog current input module. The input module provides 16 single-ended input channels. When installing the IC694ALG233 input module in a dangerous place, you must turn off the power before replacing or connecting cables. In addition, modules should not be connected to or disconnected from the PLC unless the main system power is turned off. The IC694ALG233 input module draws 120 mA current from the +5 V DC bus on the system backplane. In addition to loop current, the IC694ALG233 input module draws 65 mA current from a 24 V DC rated external power supply. The IC694ALG233 input module can withstand the external voltage ripple of 10%. The voltage range of the external power supply is 20 to 30 volts DC. The rated input low-pass filter response is 23 Hz

There are 16 channels on the IC694ALG233 input module, each of which can be configured with the following input ranges: 0 to 20 mah, 4 to 20 mah enhanced, and 4 to 20 mah normal. The upper and lower alarm limits can also be configured via software. For an enhanced current range of 4 to 20 mA, a lower alarm limit can be configured to detect input currents between 4 and 20 mA. This feature can be used to provide line break detection in enhanced current rating applications ranging from 4 to 20 mA. The IC694ALG233 input module also reports the module status and external power supply status to the system CPU using the assigned program reference address. The IC694ALG233 input module can be installed in an I/O slot with a serial connector. The IC694ALG233 input module supports hot swap. The firmware on the IC694ALG233 input module can be upgraded to enable new features.
