IC698CRE040 是一款PACSystem RX7i处理器模块

IC698CRE040 是一款PACSystem RX7i处理器模块

IC698CRE040是GE Fanuc / Emerson Automation中央处理器（CPU）。此 CPU 支持高可用性或冗余配置的配置。该模块是 PACSystem RX7i 可编程自动化控制器 （PAC） 平台的一部分。该CPU单元具有相对较高的随机存取存储器（RAM）和非易失性存储器，两者各占64MB。此外，它还配备了一个高速微处理器，时钟速度为 1.8 GHz，每 1000 个布尔触点/线圈的扫描速率为 0.024ms。

该IC698CRE040配有嵌入式通信端口，例如两 （2） 个支持 RS232 和 RS485 通信标准的串行通信端口和两 （2） 个用于以太网连接的 RJ45 端口，支持 10/100 Mbps 半双工/全双工的传输速率，具有自动感应功能。该 CPU 还配有一 （1） 个工作站管理器端口。串口支持的协议有Modbus RTU Slave、SNP、Serial I/O。

此外，内置以太网接口能够使用以太网全局数据 （EGD） 进行数据交换，使用 SRTP 提供 TCP/IP 通信服务，支持 SRTP 通道、Modbus/TCP 服务器和 Modbus/TCP 客户端、完整的编程和配置服务、与以太网上的 SNTP 时间服务器的时间同步（与 5.00 或更高版本的 CPU 模块一起使用时）。以太网端口zui多支持 16 个 Web 服务器和 FTP 连接。

该CPU支持梯形图、C、结构化文本和功能块图等编程语言。此 CPU zui多可下载 512 个块，每个块的zui大大小为 128KB。

该IC698CRE040使用 Proficy Machine Edition 应用软件或 Logic Developer 编程软件进行配置。

GE Fanuc IC698CRE040 CPU 是一款支持以太网端口的 CPU，与 Rx7i PACsystem 兼容。CPU 的处理速度为 1.8 GHz，内存为 64 MB。它的额定电压为 +5 伏直流，额定电流为 6.8 安培。它支持浮点数据和快速操作。CPU模块设计有3个串口，兼容不同的串口协议，包括MODBUS RTU从站、SNP和串口I/O协议。对于嵌入式通信，IC698CRE040 CPU 使用 RS-232、以太网和 RS-485 接口。可以使用Proficy Machine Edition或Logic Developer编程软件对CPU进行编程。它可以处理机器控制和物料搬运应用。它使用 VME 64 标准格式与 I/O 模块和其他模块进行通信。要连接其他人机界面设备和编程器单元，可以使用以太网端口或串行端口。

GE Fanuc IC698CRE040 CPU 安装了具有备用冗余的 Pentium M 微处理器。IC698CRE040 CPU 可用于通过使用 16 个 Web 服务器和其他 FTP 连接来监控数据。CPU 带有一个内置时钟，由电池备份。可以使用 RS 232 和 485 端口将 IC698CRE040 CPU 升级到zui新的固件版本。CPU 可以检测电池电量不足的情况，并在发生不同事件时向操作员发出警报。CPU 模块具有开放式外壳，需要安装在干燥且无空气污染物的地方。

IC698CRE040 是一款PACSystem RX7i处理器模块

The IC698CRE040 is a GE Fanuc/Emerson Automation Central Processing unit (CPU). This CPU supports high availability or redundancy configurations. The module is part of the PACSystem RX7i Programmable Automation Controller (PAC) platform. This CPU unit has relatively high random access memory (RAM) and non-volatile memory, each accounting for 64MB. In addition, it is equipped with a high-speed microprocessor with a clock speed of 1.8 GHz and a scan rate of 0.024ms per 1000 Boolean contacts/coils.

The IC698CRE040 is equipped with embedded communication ports, such as two (2) serial communication ports supporting RS232 and RS485 communication standards and two (2) RJ45 ports for Ethernet connectivity, supporting 10/100 Mbps half duplex/full duplex transmission rates. With automatic sensing function. The CPU is also equipped with one (1) workstation manager port. The Serial port supports Modbus RTU Slave, SNP, and Serial I/O protocols.

In addition, the built-in Ethernet interface can use Ethernet Global Data (EGD) for data exchange, use SRTP to provide TCP/IP communication services, Support SRTP channel, Modbus/TCP server and Modbus/TCP client, complete the programming and configuration services, and Ethernet SNTP time server time synchronization (with version 5.00 or higher CPU module when using). The Ethernet port supports up to 16 Web servers and FTP connections.

The CPU supports programming languages such as ladder diagram, C, structured text, and function block diagram. This CPU can download up to 512 blocks, each with a maximum size of 128KB.

The IC698CRE040 is configured using Proficy Machine Edition application software or Logic Developer programming software.

GE Fanuc IC698CRE040 CPU is a support Ethernet port of the CPU, and Rx7i PACsystem compatible. Processing speed of 1.8 GHz CPU, memory is 64 MB. It has a rated voltage of +5 volts DC and a rated current of 6.8 amps. It supports floating-point data and fast operations. The CPU module is designed with three serial ports and is compatible with different serial port protocols, including MODBUS RTU slave station, SNP, and serial port I/O protocols. For embedded communications, the IC698CRE040 CPU uses RS-232, Ethernet, and RS-485 interfaces. The CPU can be programmed using Proficy Machine Edition or Logic Developer programming software. It can handle machine control and material handling applications. It uses the VME 64 standard format to communicate with I/O modules and other modules. To connect other HMI devices and programmer units, you can use Ethernet ports or serial ports.

GE Fanuc IC698CRE040 installed with standby redundancy CPU Pentium M microprocessor. IC698CRE040 CPU can be used for 16 through the use of the Web server and other FTP connection to monitoring data. With a built-in CPU clock, by the backup battery. The IC698CRE040 CPU can be upgraded to the latest firmware version using RS 232 and 485 ports. The CPU can detect when the battery is low and alert the operator when different events occur. The CPU module has an open housing and needs to be installed in a dry and free of air pollutants.

IC698CRE040 是一款PACSystem RX7i处理器模块
