该IC698ETM001是由艾默生自动化（前身为 GE Fanuc Automation）制造的以太网接口模块。该模块是 PACSystem RX7i 可编程自动化控制器 （PAC） 平台的一部分，使任何安装了 IC698ETM001 模块的机架都能连接到现有的以太网工作，以便与驻留在同一网络中的其他控制器进行数据交换、远程 I/O 实施、与可视化系统和第三方软件和工具（如数据库和企业软件应用程序）进行通信。

IC698ETM001具有两 （2） 个以太网端口，机器人能够以 10/100 Mbps 的通信速度传输数据，并具有自动感应功能。这些端口设计为使用 RJ45 连接器和zui少的 CAT5 电缆进行物理连接。这些端口支持菊花链，允许形成线性、星形和环形拓扑，并支持唯 一或冗余 IP 寻址。此外，它还具有一 （1） 个串行通信端口，即 9 针 sub-D 连接器，支持 1200 - 115200 bps 的传输速度。此端口基本上是一个 Station Manager 端口，用于对模块执行配置。

该IC698ETM001支持多种通信协议，例如使用服务请求传输协议 （SRTP） 的 TCP/IP 通信服务、SRTP 客户端、MODBUS TCP 服务器和 MODBUS TCP 客户端。此外，该模块还支持与以太网上的SNTP时间服务器进行时间同步。

该IC698ETM001配备了各种 LED 指示灯，可提供模块当前状态的概览。这些 LED 是 MODULE OK、LAN ONLINE、STATUS、100、LINK P1 和 100、LINK P2。该模块配备了专用的微处理器，使该模块能够以 200 MHz 的速度执行处理能力。 IC698ETM001模块配备了不同的 LED 来指示不同的事件。

它带有 MODULE OK、LAN ONLINE、STATUS、100 LINK P1 和 100 LINK P2 LED。它一次只能容纳 1 个 IP 地址。

IC698ETM001模块配备两个 10 Base T/100 Base Tx 连接器，需要 RJ 45 连接器、8 针母连接器以建立与总线的连接。以太网模块允许以菊花链方式连接以太网节点。该模块具有对操作员有帮助的站点管理和诊断工具。IC698ETM001模块处理冗余 IP 寻址、与遥控器的通信以及通过 SNTP 服务器进行时间同步。该模块可用于与网络集线器直接连接，无需外部收发器。它可以轻松地将应用程序进程存储在其闪存中，并且可以通过使用CPU串口轻松升级。IC698ETM001模块符合全球使用所需的电气和环境标准。
