产品描述
该IS200TBCIH1CCD是带组隔离板的触点输入。它用于 Mark VI Speedtronic 系统。该IS200TBCIH1CCD也可用于MKVIe系统。

IS200TBCIH1CCD与VTCC/VCRC或PDIA I/O包接口，具体取决于其使用的系统。该板接受 24 个干接点输入。它们连接到电路板的接线端子。每个都有 12 个屏障型块。该板具有标称 125 VDC 浮动激励电压。这范围从 100 到 145 Vdc。

IS200TBCIH1CCD 有三个 d-shell 型连接器。这些允许连接电缆连接器。连接器是带闩锁紧固件的 37 针连接器。

IS200TBCIH1CCD上的接线端子通常每个连接点使用 #12 AWG 电线。当需要维护时，可以将电路板的接线端子从电路板上拔下。

有关IS200TBCIH1CCD功能的其他信息，请参阅通用电气手册或用户指南。这些出版物还将提供有关安装、维护和适当安全程序的详细信息。只有训练有素的技术人员才能处理、维护或安装 Mark VI 设备。

IS200TBCIH1CCD 涡轮控制 PCB 板 是带组隔离板的触点输入
Product description
The IS200TBCIH1CCD is the contact input of the tape isolation plate. It is used in Mark VI Speedtronic systems. The IS200TBCIH1CCD is also available for MKVIe systems.

The IS200TBCIH1CCD interfaces with VTCC/VCRC or PDIA I/O packages, depending on the system it is used on. The board accepts 24 dry contact inputs. They are connected to the wiring terminals of the circuit board. Each has 12 barrier blocks. The board has a nominal 125 VDC floating excitation voltage. This ranges from 100 to 145 Vdc.

The IS200TBCIH1CCD has three d-shell connectors. These allow the connection of cable connectors. The connector is a 37-pin connector with latch fasteners.

Terminals on IS200TBCIH1CCD usually use #12 AWG wires per connection point. When maintenance is required, remove the wiring terminals from the circuit board.

For additional information about the features of the IS200TBCIH1CCD, please refer to the General Electric manual or user Guide. These publications will also provide detailed information on installation, maintenance and proper safety procedures. Only trained technicians can handle, maintain, or install Mark VI equipment.
