IS200TBTCH1C 热电偶输入端子板 设计用于通用电气的Mark VIe控制系统

IS200TBTCH1C 热电偶输入端子板 设计用于通用电气的Mark VIe控制系统

产品描述
热电偶输入 （TBTC） 端子板IS200TBTCH1C是通用电气生产的 Mark VIe 系列的一部分。该板将接受 T、S、K、J 和 E 主 24 英寸热电偶输入。如果该板与单工系统中的 PTCCH2 板一起使用，则该板可以接受标记为 R、B 和 N 的额外三个热电偶输入。有两种 TBTC 型号，该型号是IS200TBTCH1C表示它有两个 DC 型连接器，并且仅用于单工应用。该板将使用两个PTCC封装，因此允许24个输入。

当将 IS200TBTCH1C 板作为 Mark VIe 系列的一部分连接时，所使用的 I/O 包将直接校正到 TBTC J 型连接器中，所需的电缆也将取决于板所需的冗余级别。该板的一个特点是该板上的热电偶输入可以不接地或接地。 输入端距离涡轮机控制面板zui远可达 984 英尺。此设备上连接的 I/O 处理器将对各个热电偶输入执行模数线性化和转换。

IS200TBTCH1C板的热电偶输入可以支持从负 8 伏到高达 45 伏的正输入范围的宽输入范围。该板具有冷端，其工作范围为负 22 度至 149 华氏度。冷端或CJ信号可通过进入信号空间进行监测。

IS200TBTCH1C 热电偶输入端子板 设计用于通用电气的Mark VIe控制系统
Product description
The Thermocouple Input (TBTC) terminal board IS200TBTCH1C is part of the Mark VIe series produced by General Electric. The board will accept T, S, K, J and E main 24-inch thermocouple inputs. If the board is used with a PTCCH2 board in a simplex system, the board can accept three additional thermocouple inputs labeled R, B, and N. There are two TBTC models, the model is IS200TBTCH1C indicating that it has two DC type connectors and is only used for simplex applications. The board will use two PTCC packages, thus allowing 24 inputs.

When connecting the IS200TBTCH1C board as part of the Mark VIe series, the I/O packages used will be corrected directly into the TBTC Type J connector, and the cables required will also depend on the level of redundancy required for the board. A feature of the board is that the thermocouple input on the board can be ungrounded or grounded. The input can be up to 984 feet from the turbine control panel. The connected I/O processor on this device performs analog-digital linearization and conversion of the individual thermocouple inputs.

The thermocouple input of the IS200TBTCH1C board can support a wide input range from negative 8 volts to a positive input range of up to 45 volts. The plate has a cold end and its operating range is negative 22 degrees to 149 degrees Fahrenheit. Cold end or CJ signals can be monitored by entering the signal space.

IS200TBTCH1C 热电偶输入端子板 设计用于通用电气的Mark VIe控制系统
