IS200TTURH1C是通用电气的终端板。 该板旨在与该公司后来的Speedtronic系统兼容。这包括Mark VI和Mark VIe系统。AX Control 为这两个系统以及早期 Speedtronic 系统的组件提供随时可发货的现有库存。自 1960 年代后期zui早的迭代 （Mark I） 可用于工业燃气轮机和蒸汽轮机管理以来，Speedtronic 系统逐渐变得更加复杂。IS200TTURH1C主要是矩形的，有一些小切口，允许更改电路板电路以允许单工或 TMR 投票。

该板与其他 PCB 如 PTUR 和 VTUR 板一起使用，以控制发电机的同步. 这主要是通过硬件和连接完成的。IS200TTURH1C具有多个表面安装继电器。此外，该板使用可变电阻器，并且在电路板中心附近还有两个变压器。与其他电路板组件的通信通过 d-shell 连接器（公头和母头）、插头连接器和接线端子进行。电路板上zui大的两个接线端子具有螺钉安装的连接器。该IS200TTURH1C还包括两个跳线开关。

IS200TPROH1C 终端板 可用于工业燃气轮机和蒸汽轮机管理
The IS200TTURH1C is a General Electric terminal board. The board was designed to be compatible with the company's later Speedtronic system. This includes the Mark VI and Mark VIe systems. AX Control provides ready-to-ship existing inventory of components for both systems, as well as earlier Speedtronic systems. Since the earliest iterations (Mark I) became available for industrial gas turbine and steam turbine management in the late 1960s, Speedtronic systems have gradually become more complex. The IS200TTURH1C is mostly rectangular, with some small cutouts that allow the board circuit to be changed to allow simplex or TMR voting.

The board is used with other PCBS such as PTUR and VTUR boards to control the synchronization of the generator. This is mostly done through hardware and connectivity. The IS200TTURH1C features multiple surface-mounted relays. In addition, the board uses variable resistors, and there are two transformers near the center of the board. Communication with other board components occurs through d-shell connectors (male and female), plug connectors, and terminal blocks. The two largest terminals on the board have screw-mounted connectors. The IS200TTURH1C also includes two jumper switches.
