产品描述
IS220PAICH1B型号由通用电气生产，是 Mark VI 系列的模拟输入/输出包的一部分。该型号是PAIC单元的第二个版本，与之前版本的PAIC电池组相比，在不同的zui小电压下运行。该特定单元的zui小电压是 22 伏半的直流电。该型号使用的标称电源是 24 或 28 伏的直流电。

虽然 Mark VI 系列中使用了 IS220PAICH1B 包，但它可以与一些也称为端子板的附件一起使用;与此特定模拟 I/O 包一起使用的端子板都是 IS200 板，并且是 IS200TBAIH1C、IS200TAIH1A和IS200TAIH2A。IS200TBAIH1C 型号是屏障型接线盒，与IS220PAICH1B组连接和使用时，zui小电线尺寸为 22 AWG。

使用此型号时会出现特定的警报，其中一个警报标记为 82-83，它侧重于输出并指示IS220PAICH1B包内的自杀继电器不起作用。此警报的可能原因通常是电池组中的自杀继电器命令与关联的反馈不匹配、硬件出现故障或采集板上发生继电器故障。此问题的主要解决方案是更换 I/O 包本身。

IS220PAICH1B包可用于许多不同的场所，包括危险和非危险场所，根据该模型，非危险场所的认证是 UL E207685。

IS220PAICH1B PAIC 模拟量 I/O 模块
Product description
The IS220PAICH1B model is manufactured by General Electric and is part of the analog input/output package of the Mark VI series. This model is the second version of the PAIC unit that operates at a different minimum voltage compared to the previous version of the PAIC battery pack. The minimum voltage for this particular unit is 22 and a half volts of direct current. The nominal power supply used in this model is 24 or 28 volts of direct current.

Although the IS220PAICH1B package is used in the Mark VI series, it can be used with some accessories also known as terminal boards; The terminal boards used with this particular analog I/O packet are all IS200 boards and are IS200TBAIH1C, IS200TAIH1A, and IS200TAIH2A. The IS200TBAIH1C model is a barrier junction box with a minimum wire size of 22 AWG when connected and used with the IS220PAICH1B group.

Specific alarms appear when using this model, one of which is labeled 82-83, which focuses on the output and indicates that the suicide relay inside the IS220PAICH1B package is not working. The possible cause of this alarm is usually a mismatch between the suicide relay command in the battery pack and the associated feedback, a hardware failure, or a relay failure on the acquisition board. The main solution to this problem is to replace the I/O package itself.

The IS220PAICH1B package can be used in many different sites, both hazardous and non-hazardous sites, and according to this model, the certification for non-hazardous sites is UL E207685.
