MVI56E-SIE PROSOFT 以太网通信模块

MVI56E-SIE PROSOFT 以太网通信模块

ProSoft Technology的MVI56E-SIE模块是西门子工业以太网客户端通信模块，专为ControlLogix系统设计。它允许ControlLogix PACs(可编程自动化控制器)作为以太网客户端与多达20个西门子S7-200、S7-300、S7-400、S7-1200和S7-1500 PLC接口，这些PLC作为以太网服务器工作。该模块通过了RoHS、CE和IECEx标准认证。

MVI56E-SIE模块附带以下组件:一根5英尺以太网电缆(直通配置)和一张包含模块配置工具的ProSoft solutions CD或ProSoft solutions DVD。MVI56E-SIE模块使用ProSoft配置生成器，通过图形配置工具管理配置文件，还允许查看模块诊断信息。

MVI56E-SIE模块是一个单槽1756 ControlLogix背板兼容。该模块的电流负载在5伏DC下为800毫安，在23伏DC下为3毫安。该模块支持带自动交叉检测的10/100 Mbps以太网。以太网接口是RJ-45接口，带有用于链路和活动的LED指示灯。模块上的4字符字母数字LED显示屏可用于显示状态和诊断信息。模块上还提供了LED指示灯，用于显示电池状态、应用状态和模块状态。MVI56E-SIE模块的工作温度范围为32至140华氏度，存储温度范围为-40至185华氏度。从10赫兹到150赫兹，模块的振动等级为5 G。操作冲击等级为30 G。

MVI56E-SIE PROSOFT 以太网通信模块
The MVI56E-SIE module from ProSoft Technology is a Siemens Industrial Ethernet client communication module designed for ControlLogix systems. It allows ControlLogix PACs(Programmable Automation Controller) as an Ethernet client to interface with up to 20 Siemens S7-200, S7-300, S7-400, S7-1200 and S7-1500 PLCS that work as Ethernet servers. The module is certified to RoHS, CE and IECEx standards.

The MVI56E-SIE module comes with the following components: a 5-foot Ethernet cable (pass-through configuration) and a ProSoft solutions CD or ProSoft solutions DVD with module configuration tools. The MVI56E-SIE module uses the ProSoft configuration generator to manage configuration files through the graphical configuration tool, which also allows you to view module diagnostic information.

The MVI56E-SIE module is compatible with a single slot 1756 ControlLogix backplane. The module's current load is 800 mah at 5 volt DC and 3 mah at 23 volt DC. The module supports 10/100 Mbps Ethernet with automatic cross detection. The Ethernet interface is the RJ-45 interface with LED indicators for link and activity. The 4-character alphanumeric LED display on the module can be used to display status and diagnostic information. LED indicators are also provided on the module to display battery status, application status and module status. The MVI56E-SIE module has an operating temperature range of 32 to 140 degrees Fahrenheit and a storage temperature range of -40 to 185 degrees Fahrenheit. From 10 Hz to 150 Hz, the module has a vibration rating of 5 G. The operating impact rating is 30 G.
