NFT-801RM3-S先进的运动控制已经发布了7个新的微型FlexPro伺服驱动器额定为60连续输出。60-A的持续电流额定值比相同尺寸的先前型号高33%,使这些成为该公司迄今为止功率密度zui高的伺服驱动器。该产品包括PCB安装、机器嵌入式和开发板外形。

PCB安装尺寸
凭借38.1 x 25.4毫米的尺寸，一张标准名片可容纳多达4个FlexPro伺服驱动器。PCB安装外形是zui紧凑的配置，没有连接器或外壳。它们旨在直接焊接到PCB上，以帮助实现zui高的集成度。

NFT-801RM3-S机器嵌入式外形
这些型号在PCB安装版本上增加了一个紧凑的接口卡，允许与电源线和信号线直接连接。这种外形使得在机器的任何地方安装伺服驱动器都很容易。

开发板外形
与本次产品发布中的其他型号基本相同，但安装在一个更大的板上，板上安装了全尺寸连接器，连接器之间的间距更大。开发板非常适合用于概念验证设计和在台式电脑上设置实验。

NFT-801RM3-S功能包括:

提供EtherCAT、CANopen、RS485/RS232通信

10至55 Vdc输入电压

额定持续电流为60安

增量编码器、EnDat 2.2和BISS C模式反馈

扭矩、速度和位置操作模式

配置和全环路调谐

STO(安全扭矩关闭)

影响架构NFT-801RM3-S
