产品说明
产品ID:3BDH000364R0002 ABB型号名称:PM 783F目录描述:PM 783F CPU模块详细描述:中央处理器(CPU)模块配备了高性能处理器，可实现快速循环时间。它配有板载100 Mbit/s以太网连接，用于控制器、操作员站和工程工具之间的通信。两个串行线路接口完成连接。一个接口可用于Modbus通信，而另一个用于诊断。CPU有10 MB的内存，其中2 MB是备用电池。对于要求苛刻的应用，可以配置八个周期时间可调的循环和优先级驱动任务，以及一个尽可能快速运行的循环PLC类型任务。小型前面板显示器直接在模块上显示状态和诊断信息。此外，您可以通过按键锁定控制器。这意味着可以阻止控制器下载应用程序和固件，以增强安全性。如果控制器锁定或解锁，状态将显示在显示屏上。S700 I/O模块可以直接插入CPU模块，也可以通过PROFIBUS用作远程I/O。一个控制器zui多可以连接八个模块。第三方I/O可通过MODBUS ASCII / RTU、IEC 60870-5-101遥控协议或PROFIBUS进行连接。CPU和本地S700 I/O模块的通信速度非常快。2毫秒的I/O扫描时间是可能的。每个通道都实现了短路和断线检测。类别产品控制系统自由职业者控制器AC 800F中央单元PM 803F附加信息介质描述:PM 783F是一个在PLC硬件上运行的DCS，特别适用于由几个到大约几个。300个输入/输出信号。它没有操作系统。在软件安装期间，必须加载操作系统。需要外部24伏直流电源。软件版本9.2SP2或更高版本是强制性的。对于以前版本的操作，请参考产品更新信息2PAA102068R0018。与端子座TB 711F和电池TA521一起使用。技术信息:不带操作系统。在软件安装期间，必须加载操作系统。需要外部24伏直流电源。软件版本9.2SP2或更高版本是强制性的。对于以前版本的操作，请参考产品更新信息2PAA102068R0018。与端子座TB 711F和电池TA521一起使用。产品类型:中央单元订购协调制度编码:853890 -仅适用于或主要适用于品目85.35、85.36或85.37的仪器的零件。-其他海关税则号:85389091尺寸产品净深/长:54 mm产品净高:76 mm产品净宽:67.5 mm产品净重:0.15 kg环保RoHS状态:不符合RoHS WEEE类别:5。小型设备(外部尺寸不超过50厘米)电池数量:0

PM783F 中央处理器(CPU)模块 PM783F
Product description
Product ID:3BDH000364R0002 ABB Model Name :PM 783F Catalog Description :PM 783F CPU module Details: The Central Processing Unit (CPU) module is equipped with a high-performance processor for fast cycle times. It has an onboard 100 Mbit/s Ethernet connection for communication between controllers, operator stations and engineering tools. The two serial line interfaces are connected. One interface can be used for Modbus communication and the other for diagnostics. The CPU has 10 MB of memory, of which 2 MB is the spare battery. For demanding applications, eight cycle time adjustable cycle and priority driven tasks can be configured, as well as a cycle PLC-type task that runs as fast as possible. A small front panel display displays status and diagnostic information directly on the module. In addition, you can lock the controller by pressing a button. This means that the controller can be prevented from downloading applications and firmware for increased security. If the controller is locked or unlocked, the status will be displayed on the display. The S700 I/O module can be plugged directly into the CPU module or used as remote I/O via PROFIBUS. A controller can be connected to a maximum of eight modules. Third-party I/ OS can be connected via MODBUS ASCII/RTU, IEC 60870-5-101 remote control protocol, or PROFIBUS. The communication speed between the CPU and the local S700 I/O module is very fast. An I/O scan time of 2 milliseconds is possible. Short circuit and broken line detection are realized in each channel. Category Products Control System Freelancer Controller AC 800F Central Unit PM 803F Additional Information Media Description :PM 783F is a DCS that runs on PLC hardware and is especially suitable for use from a few to about a few. 300 input/output signals. It doesn't have an operating system. During software installation, the operating system must be loaded. External 24 volt DC power supply is required. Software version 9.2SP2 or later is mandatory. For details about previous versions, see Product Update 2PAA102068R0018. Use with terminal block TB 711F and battery TA521. Technical information: No operating system. During software installation, the operating system must be loaded. External 24 volt DC power supply is required. Software version 9.2SP2 or later is mandatory. For details about previous versions, see Product Update 2PAA102068R0018. Use with terminal block TB 711F and battery TA521. Product Type: Central Unit Ordering Harmonized System Code :853890 - Parts applicable only or primarily to instruments of heading 85.35, 85.36 or 85.37. - Other Customs Tariff Code :85389091 Dimension Product Net depth/length :54 mm Product net height :76 mm product net width: 67.5mm Product net weight :0.15 kg Environmental RoHS status: not in compliance with RoHS WEEE Category :5. Small devices (external size does not exceed 50 cm) Number of batteries :0
