该装置适用于发电机侧接地故障的分段配置保护。使用REG216/316*4实现100%定子和转子接地故障保护，需要注入单元REX010和注入变压器REX011。该喷注设备适用于所有普通发电机的接地和励磁系统。
该保护在机器的所有状态中都是有效的，静止状态以及启动和运行状态。

•紧凑的设计
•与REG216/ REG316*4完美匹配
•提供整个定子绕组的保护，包括中性点
•持续监控注入电压和一次接地系统
•适用于保护区内的两个单独接地点
•对注入信号的幅度和频率进行持续的自我监控
•辅助直流电源从车站电池从36至312伏直流
•适用于所有常用的发电机接地和励磁系统
•持续监测绝缘电阻并计算接地故障电阻
•原理是基于众所周知的偏移方法，使用注入低频信号
•适用于现有工厂的更新
•对外界干扰不敏感

REX010 适用于发电机侧接地故障的分段配置保护

The device is suitable for piecewise configuration protection of generator side ground fault. 100% stator and rotor ground fault protection with REG216/316*4 requires injection unit REX010 and injection transformer REX011. The injection equipment is suitable for grounding and excitation systems of all ordinary generators.
This protection is effective in all states of the machine, at rest, as well as start-up and running states.

• Compact design
• Perfect match with REG216/ REG316*4
• Provides protection of the entire stator winding, including neutral points
• Continuous monitoring of injection voltage and primary grounding system
• Applies to two separate ground points within the protected area
• Continuous self-monitoring of the amplitude and frequency of the injected signal
• Auxiliary DC power from station battery from 36 to 312 volts DC
• Suitable for all common generator grounding and excitation systems
• Continuously monitor insulation resistance and calculate ground fault resistance
• The principle is based on the well-known offset method, using injected low-frequency signals
• Suitable for updating existing plants
• Insensitive to outside interference
