概述

ABB TVB3101-1/ISC是一种高压真空断路器，适用于50Hz的电力系统，额定电压为12kV。它可用于过载保护、短路保护和地面保护。

规格

额定电压: 12kV
额定电流: 1250A
额定短路开断电流: 31.5kA
技术说明

ABB TVB3101-1/ISC采用了高端的真空断路技术，具有更高的开断能力和更长的使用寿命。其具有可靠的操作机构和高度集成的控制器，能够满足各种应用需求。

产品参数

额定电压: 12kV
额定电流: 1250A
额定短路开断电流: 31.5kA
额定分断电流: 1250A
机械寿命: 10000次
电气寿命: 10000次
应用领域

ABB TVB3101-1/ISC广泛应用于各种电网系统、工业和公用事业电力系统，以及船舶和军事领域。

TVB3101-1/ISC ABB高压真空断路器

The ABB TU830V1 is a compact terminal.

ABB imported system industrial control automation module stock new tu830v12.

TU830V1 ABB technical description

Technical specification of ABB's TU830V1 terminal 1:

Voltage range: 100~1500V AC/DC.

Temperature range: It can work in the environment of -25~+85℃.

Installation method: Can be installed in any position, convenient and flexible.

Terminal material: made of high conductivity copper alloy, with good electrical conductivity.

Terminal structure: Modular design, which can be easily combined and replaced.

Applicable cable range: It can be applied to all standard industrial cable types, such as single or multi-core cables with a cross-sectional area of 0.3 to 240 square millimeters.

In addition, ABB's TU830V1 terminals have a dust cover design to protect against dust and moisture contamination, while a marking system makes it easy to identify the terminal type and connection method.
