东芝zui 新的工业控制器，统一nv系列控制器，是一个巨大的进步，超越了现有的V系列在世界各地的工业使用。功能包括高速逻辑，排序，电机速度控制和连续控制。高速I/O通信使用业界首 个100mbps容错环形网络“TC-net I/O”，连接远程现场安装的I/O。

这款功能强大的控制器的主要特点是:
•容错环100 Mbps I/O通信
•通过在ASIC硬件中直接执行IEC标准控制语言来提高速度
•采用冗余模块，ECC内存纠错，可靠性更高
•千兆监控网络

为了减少电气室和机器之间数百条长线路，nv控制器具有现场安装I/O模块，通过光环路与控制器通信。采用这种方法，可以大大降低布线材料和人工成本。为了保护模块免受接近机械的条件，外壳的等级为IP54，可防止灰尘，振动，水飞溅和滴水。字段I/O安装在如下所示的机柜中。

两个网络将控制器与输入/输出模块连接起来:
•电环(蓝色)服务控制器本地I/O
•光学环(红色)为机器提供本地分布式I/O服务。现场I/O安装在如下所示的机柜中。

UTLH21 TOSHIBA 工业控制器  nv控制器具有现场安装I/O模块

Toshiba's latest industrial controller, the Unified nv Series controller, is a huge step forward that goes beyond the existing V Series in industrial use around the world. Features include high-speed logic, sequencing, motor speed control and continuous control. The high-speed I/O communication uses the industry's first 100mbps fault-tolerant ring network, TC-net I/O, to connect to the I/O installed remotely in the field.

The key features of this powerful controller are:
• Fault-tolerant loop 100 Mbps I/O communication
• Increase speed by directly executing IEC standard control language in ASIC hardware
• Redundant modules, ECC memory error correction, higher reliability
• Gigabit monitoring network

To reduce the hundreds of long lines between the electrical room and the machine, the nv controller has a field-mounted I/O module that communicates with the controller via a halo path. Using this method, wiring materials and labor costs can be greatly reduced. To protect the module from near-mechanical conditions, the housing is rated IP54 and protects against dust, vibration, water splashing and dripping. Field I/O is installed in the cabinet shown below.

Two networks connect the controller to the input/output modules:
• Electric ring (blue) Local I/O of the service controller
• The optical ring (red) provides local distributed I/O services to the machine. Onsite I/ OS are installed in the following cabinet.
