VMIVME-2510B 模拟量输出模块 用于控制和数据寄存器

VMIVME-2510B 模拟量输出模块 用于控制和数据寄存器

特征：每个 8 位端口的方向可单独编程，64 mA 灌电流能力（15 mA 拉电流），用于控制和数据寄存器的单独板地址解码，用于故障检测和隔离的内置测试逻辑，高可靠性 DIN 型 I/O 连接器，8 位、16 位、32 位传输。VMIVME-2510B 是 VMIC 超级模块系列的成员，该系列具有通用的编程功能。子系统可以配置 连续的 I/O 地址以节省内存。

这些产品（VMIVME-1110、VMIVME-2120、VMIVME-2130 和 VMIVME-2510B）都是经过精心设计的 具有两组板地址开关，可为 CSR 和 I/O 地址提供高效的内存地址映射。

可以设置CSR地址开关，以便系统中各种板中的所有CSR都可以映射到连续的内存位置。Megamodule 产品还设计用于支持 8 位、16 位和 32 位数据传输。VMIVME-2510B 中设计了特定的硬件，以支持内置测试功能。VMIVME-2510B 支持离线和在线故障检测和隔离。前面板故障 LED 用于指示此板上是否存在故障。上电或复位时，LED 亮起。成功完成板级诊断后，LED 可以熄灭。

VMIVME-2510B 模拟量输出模块 用于控制和数据寄存器

Features: Individually programmable orientation for each 8-bit port, 64 mA feed current capability (15 mA pull current), individual board address decoding for control and data registers, built-in test logic for fault detection and isolation, high-reliability DIN type I/O connectors, 8-bit, 16-bit, 32-bit transfers. The VMIVME-2510B is a member of the VMIC Supermodule family, which has universal programming capabilities. The subsystem can be configured with consecutive I/O addresses to save memory.

These products (VMIVME-1110, VMIVME-2120, VMIVME-2130, and VMIVME-2510B) are carefully designed with two sets of board address switches to provide efficient memory address mapping for CSR and I/O addresses.

The CSR address switch can be set so that all CSRS in the various boards in the system can be mapped to successive memory locations. Megamodule products are also designed to support 8-bit, 16-bit, and 32-bit data transfers. Specific hardware has been designed in the VMIVME-2510B to support built-in testing capabilities. The VMIVME-2510B supports offline and online fault detection and isolation. The front panel Fault LED is used to indicate whether there is a fault on this board. When powered on or reset, the LED lights up. After the board level diagnosis is successfully completed, the LED can be turned off.

VMIVME-2510B 模拟量输出模块 用于控制和数据寄存器
