620-001-001-116 XMV16适用于监测点较多的应用

620-001-001-116 XMV16适用于监测点较多的应用

完整系统的振动监测
测量和监测振动有多种选择，从具有集成振动监测的完整监测系统到简单的振动变送器。

振动监测；可选或集成
Istec 提供具有可选和集成监控功能的监控系统。

VM600
VM600 是zui先进的旋转机械振动监测和监控系统。该系统具有高通道密度，使其适用于监测点较多的应用，例如完整的机组和复杂的安装。监控功能可以选择性地添加到控制功能中。该系统可以与 VibroSight®、Vibro-Meter (Meggitt) 振动监测和分析软件包集成。
VSV301
VSV301 是zui先进的旋转机械振动控制和监测系统。该系统可从 2 个通道扩展，使其成为小型应用的理想选择。该系统可以独立运行，也可以与带有 VibroSight® 的 VM600 集成，Vibro-Meter (Meggitt) 振动监测和分析软件包。

使用变送器进行振动监测（模拟输出）
Istec RecipSys 200
RecipSys 200 是一种基于变送器的系统，用于监测往复式压缩机上的活塞杆位移，以准确实时了解支撑带磨损情况。它使用相位触发器以正确的相位角过滤来自活塞杆的位移信号（杆位移）。

矩阵 - VM600 XMV16
Metrix 的 VM600 XMV16 是一款双通道 DIN 导轨信号调节器，可接收来自速度传感器、加速度计和接近探头的信号。可自由编程的变送器提供简单的监视和监控功能。

矩阵 - VM600 XMV16
Metrix 的 VM600 XMV16 是一款单通道振动变送器。变送器可直接安装在机器外壳或轴承上，并具有内置传感器和信号调节器。ST5484E 为简单的振动监测提供了一种经济高效的解决方案。

监控软件
VibroSight® 是来自 Vibro-Meter (Meggitt) 的zui先进的振动监测和分析软件包，可与 VibroSmart 和 VM600 系统配合使用。该软件包提供了用于监测和分析振动数据的广泛选项。该软件提供的对机器状况的广泛洞察有助于基于状态的维护，从而延长机器的使用寿命和正常运行时间。

、

620-001-001-116 XMV16适用于监测点较多的应用

Vibration monitoring of complete systems
There are many options for measuring and monitoring vibration, from complete monitoring systems with integrated vibration monitoring to simple vibration transmitters.

Vibration monitoring; Optional or integrated
Istec offers monitoring systems with optional and integrated monitoring functions.

VM600
VM600 is the most advanced vibration monitoring and monitoring system for rotating machinery. The high channel density of the system makes it suitable for applications with a large number of monitoring points, such as complete units and complex installations. Monitoring functions can optionally be added to control functions. The system can be integrated with VibroSight® and Vibro-Meter (Meggitt) vibration monitoring and analysis packages.
VSV301
The VSV301 is the most advanced vibration control and monitoring system for rotating machinery. The system can be scaled up from 2 channels, making it ideal for small applications. The system can operate independently or be integrated with the VM600 with VibroSight®, Vibro-Meter (Meggitt) vibration monitoring and analysis software package.

Vibration monitoring with transmitter (analog output)
Istec RecipSys 200
RecipSys 200 is a transducer-based system that monitors piston rod displacement on reciprocating compressors to get an accurate real-time view of support band wear. It uses a phase trigger to filter the displacement signal (rod displacement) from the piston rod at the correct phase Angle.

Matrix - VM600 XMV16
Metrix's VM600 XMV16 is a dual-channel DIN rail signal regulator that receives signals from speed sensors, accelerometers and proximity probes. The freely programmable transmitter provides simple monitoring and monitoring functions.

Matrix - VM600 XMV16
Metrix's VM600 XMV16 is a single channel vibration transmitter. The transmitter can be mounted directly on the machine housing or bearing and has a built-in sensor and signal regulator. The ST5484E provides a cost-effective solution for simple vibration monitoring.

Monitoring software
VibroSight® is the most advanced vibration monitoring and analysis software package from Vibro-Meter (Meggitt) that works with VibroSmart and VM600 systems. The package offers a wide range of options for monitoring and analyzing vibration data. The extensive insight into the condition of the machine provided by the software facilitates condition-based maintenance, thereby extending the service life and uptime of the machine.
