1900/65A通用设备监视器的设计是连续监控和保护在各种应用中使用的设备行业。该显示器的低成本使其成为通用的理想解决方案可以从持续监控中受益的机器和过程保护。

输入1900/65A提供四个传感器输入和四个温度输入。

软件可以配置每个传感器输入支持2线和3线加速度计，速度传感器或接近传感器。每个温度输入支持E型、J型、K型和T型热电偶，以及2线或3线rtd。

输出1900/65A提供六个继电器输出，四个4-20 mA记录器输出，和一个专用缓冲输出。用户可以使用1900组态软件配置继电器触点根据OK, Alert和任何通道或通道组合的危险状态，并提供数据

从任何记录器输出的任何通道的任何变量。专用的缓冲输出可以为每个换能器输入提供信号。ModbusGateway选项允许监视器提供静态变量，将状态、事件列表、时间和日期信息直接发送到任何Modbus客户端，

包括分布式控制系统(dcs)、监控和数据采集(SCADA)系统，可编程逻辑控制器(plc)或系统1软件。监视器使用一个内部计数器和一个Modbus客户端/主机

时间引用来生成时间和日期信息。用户可以升级没有Modbus网关的显示器，订购1900/01通信升级(参见订购信息部分)。的1900/65A支持通过以太网和软件配置的Modbus通信RS232/485串行端口。

19047-01 通用设备监视器的设计是连续监控

The 1900/65A Universal Device Monitor is designed to continuously monitor and protect equipment used in a variety of applications in the industry. The low cost of the display makes it an ideal solution for universal machine and process protection that can benefit from continuous monitoring.

Input 1900/65A provides four sensor inputs and four temperature inputs.

The software can be configured for each sensor input to support 2-wire and 3-wire accelerometers, speed sensors or proximity sensors. Each temperature input supports type E, J, K, and T thermocouples, as well as 2-wire or 3-wire RTDS.

The 1900/65A offers six relay outputs, four 4-20 mA recorder outputs, and a dedicated buffer output. Users can use the 1900 configuration software to configure relay contacts according to OK, Alert and any channel or channel combination of hazardous states, and provide data

Any variable on any channel output from any logger. A dedicated buffer output can provide a signal for each transducer input. The ModbusGateway option allows the monitor to provide static variables that send status, event list, time and date information directly to any Modbus client.

Include distributed control systems (dcs), supervisory control and Data acquisition (SCADA) systems, programmable logic controllers (PLCS), or System 1 software. The monitor uses an internal counter and a Modbus client/host

Time references to generate time and date information. Users can upgrade displays without the Modbus gateway by ordering the 1900/01 communications upgrade (see Ordering Information section). The 1900/65A supports RS232/485 serial port communication over Ethernet and software-configured Modbus.
