3500/22M 138607-01 瞬态数据接口模块 属于3500系列组件

3500/22M 138607-01 瞬态数据接口模块 属于3500系列组件

工作温度:-30至+65摄氏度
储存温度:-40至+85摄氏度
湿度:95%，非冷凝
无动力TDI: 12年- 50摄氏度
协议:BN主机。
波特率:zui大115.2千波特
供货情况:有现货
制造国:美国(美国)

功能描述
138607-01是由本特利内华达公司开发的瞬态数据接口模块。它属于3500系列组件。瞬态数据接口(TDI)将3500监控系统连接到GE的System 1机械管理软件。TDI结合了3500/20 RIM的功能和TDXnet等通信处理器的数据收集功能。

配置键锁
用于将3500架设置为运行或编程模式。运行模式允许正常的试管架操作，但阻止配置更改。
PROGAM模式允许正常的机架操作以及本地或远程机架配置。
在任何位置都可以从机架上取下钥匙，使交换机保持运行或编程状态。将交换机锁定在运行位置可防止未经授权的机架重新配置。当开关锁定在程序位置时，可以随时远程重新配置机架。
前面板发光二极管
正常LED:指示3500/22M何时正常运行
TX/RX LED:指示3500/22M何时与机架中的其他模块通信。
TM LED:指示3500架何时处于行程倍增模式。
配置正常LED:表示3500框架具有有效的配置。
警报数据收集
报警前后的数据。
事件发生前10分钟和事件发生后1分钟收集1秒钟的静态数据。
事件发生前20秒和事件发生后10秒收集100毫秒的静态值。
报警前每隔10秒收集2.5分钟的波形数据，报警后每隔10秒收集1分钟的波形数据

3500/22M 138607-01 瞬态数据接口模块 属于3500系列组件

Operating temperature :-30 to +65 degrees Celsius
Storage temperature :-40 to +85 degrees Celsius
Humidity :95%, non-condensing
Unpowered TDI: 12 years -50 degrees Celsius
Protocol :BN host.
Baud rate: maximum 115.2 thousand baud
Availability: In stock
Country of Manufacture: USA (USA)

Function description
138607-01 is a transient data interface module developed by Bentley Nevada Corporation. It belongs to the 3500 series of components. The Transient Data Interface (TDI) connects the 3500 monitoring System to GE's System 1 mechanical management software. TDI combines the capabilities of 3500/20 RIM with the data collection capabilities of communication processors such as TDXnet.

Configuration key lock
Used to set 3500 units to run or program mode. Run mode allows normal tube rack operation, but prevents configuration changes.
PROGAM mode allows normal rack operation as well as local or remote rack configuration.
The key can be removed from the rack in any position to keep the switch running or programmed. Locking the switch in a running position prevents unauthorized rack reconfiguration. When the switch is locked in the program position, the rack can be remotely reconfigured at any time.
Front panel LED
Normal LED: Indicates when 3500/22M is operating normally
TX/RX LED: Indicates when the 3500/22M is communicating with other modules in the rack.
TM LED: Indicates when 3500 are in travel doubling mode.
Normal LED configuration: indicates that the 3500 frame has a valid configuration.
Alarm data collection
Before and after the alarm.
1 second static data is collected 10 minutes before the event and 1 minute after the event.
Static values of 100 milliseconds are collected 20 seconds before the event and 10 seconds after the event.
2.5 minutes of waveform data is collected every 10 seconds before the alarm, and 1 minute of waveform data is collected every 10 seconds after the alarm

3500/22M 138607-01 瞬态数据接口模块 属于3500系列组件
