PPD113B01-10-150000 3BHE023784R0123 高功率直流电源

PPD113B01-10-150000 3BHE023784R0123 高功率直流电源

产品参数
型号：PPD113B01-10-150000
订单号：3BHE023784R1023
额定电压：110-240V AC
频率：50/60Hz
额定功率：1500W
zui大输出电压：300V DC
zui大输出电流：5A
工作温度：-20℃至+60℃
存储温度：-40℃至+70℃
保护等级：IP20
产品规格
尺寸：380mm x 150mm x 200mm
重量：4.2kg
材质：铝合金外壳
适用电缆截面：0.5mm²至10mm²
输出接口：4mm插针
应用领域
该产品适用于电池充电、电动工具、电动车等领域。

产品使用说明
使用前请仔细阅读产品说明书，确保安装正确。
请勿超负荷使用，以免损坏产品。
在使用过程中，如出现异常情况，请及时停止使用，并联系售后人员处理。
产品介绍
ABB PPD113B01-10-150000 3BHE023784R1023是一款高功率直流电源，具有稳定的输出电压和电流，可广泛应用于电池充电、电动工具、电动车等领域。产品采用铝合金外壳，外形美观，散热性能良好，使用寿命长。

PPD113B01-1-150000 3BHE023784R0123 高功率直流电源

Product parameter
Model: PPD113B01-10-150000
Order number: 3BHE023784R1023
Rated voltage: 110-240V AC
Frequency: 50/60Hz
Rated power: 1500W
Maximum output voltage: 300V DC
Maximum output current: 5A
Operating temperature: -20℃ to +60℃
Storage temperature: -40℃ to +70℃
Protection level: IP20
Product specification
Size: 380mm x 150mm x 200mm
Weight: 4.2kg
Material: Aluminum alloy shell
Applicable cable section: 0.5mm² to 10mm²
Output interface: 4mm pin
Application field
The product is suitable for battery charging, power tools, electric vehicles and other fields.

Product instructions
Please read the product manual carefully before use to ensure that the installation is correct.
Do not overload the use, so as not to damage the product.
In the process of use, if there is any abnormal situation, please stop the use in time, and contact the after-sales personnel for handling.
Product introduction
ABB PPD113B01-10-150000 3BHE023784R1023 is a high power DC power supply with stable output voltage and current, which can be widely used in battery charging, power tools, electric vehicles and other fields. The product uses aluminum alloy shell, beautiful appearance, good heat dissipation performance, long service life.

PPD113B01-10-150000 3BHE023784R0123 高功率直流电源
