CLS208 温度控制器模块 允许快速设置控制器

CLS208 温度控制器模块 允许快速设置控制器

Watlow的SERIES CLS200是一款功能强大的控制器，结合性能和灵活性与紧凑的设计。4、8和16回路版本提供完整的控制器为广泛的应用提供解决方案。支持多种类型的传感器输入可用，包括热电偶，rtd，线性电压，电流和频率。
每个控制器都可以作为一个独立的系统运行，并且包括内置串行通信的计算机接口数据采集。可选的可编程斜坡和浸泡功能允许复杂的批量处理和排序。
增强的功能选项提供级联控制，比率控制，微分控制，过程变量重传和远程模拟设定点。
系列CLS200控制器通过UL®和C-UL®认证符合欧共体EMC要求指令并带有CE标志。

特点和优点
PID控制多达16个加热和冷却回路
•zui小化面板空间每个循环
•减少安装时间
•提高可靠性:更少的零件意味着更少的故障调音
•需要更少的时间调整
•以较少的专业知识实现卓越的控制菜单引导操作与全文显示
•允许快速设置控制器
•简化操作存储和召回8个工作
•从一个过程到另一个过程的快速变化多重和混合输入
•接受热电偶，rtd，线性的组合直流电压和线性直流电流传感器
•减少学习曲线和库存传感器故障检测
•减少故障排除时间反转，短路和开放的传感器每个输入的高/低过程和偏差报警
•根据需要与PLC和其他设备集成控制元素34个数字输出
•配置灵活
•允许根据需要使用控制和报警输出EIA/TIA-232和485通信
•连接到软件，方便配置和操作
•允许与控制器和软件集成

CLS208 温度控制器模块 允许快速设置控制器

Watlow's SERIES CLS200 is a powerful controller that combines performance and flexibility with a compact design. The 4, 8 and 16-loop versions offer complete controller solutions for a wide range of applications. Support for multiple types of sensor inputs is available, including thermocouples, RTDS, linear voltages, currents and frequencies.
Each controller can operate as an independent system and includes computer interface data acquisition with built-in serial communication. Optional programmable ramp and soak functions allow complex batch processing and sorting.
Enhanced feature options provide cascade control, ratio control, differential control, process variable retransmission, and remote simulation setpoints.
The series CLS200 controllers are UL® and C-UL® certified to comply with the EC EMC Requirements Directive and bear the CE mark.

Features and advantages
PID controls up to 16 heating and cooling circuits
• Minimize panel space per loop
• Reduce installation time
• Improved reliability: Fewer parts means fewer fault tunings
• Requires less time to adjust
• Superior control menu guidance and full-text display with less expertise
• Allows quick controller setup
• Simplify operation storage and recall 8 jobs
• Rapid changes in multiple and mixed inputs from one process to another
• Accepts thermocouples, RTDS, linear combined DC voltage and linear DC current sensors
• Reduce learning curve and inventory sensor failure detection
• Reduce troubleshooting time for inversion, short circuits and open sensors per input for high/low process and deviation alarms
• 34 digital outputs to integrate control elements with PLCS and other devices as needed
• Flexible configuration
• Allows the use of control and alarm output EIA/TIA-232 and 485 communication as needed
• Connect to software for easy configuration and operation
• Allows integration with controllers and software
