DS200SLCCG2A是一种LAN(局域网)通信板。 通用电气公司开发了这种板，作为Mark V系列驱动板的一员。ge品牌的一系列驱动器都设计为在其驱动器机柜中安装此板。安装该板后，主机可获得所需的LAN接口处理空间。该板包括DLAN网络通信所需的电路。

安装DS200SLCCG2A板时，主机驱动器提供两个非隔离和隔离通信电路。板上的主要元件是局域网控制处理器。该处理器用于过滤和处理发送到电路板的信号。 两个可拆卸的EPROM存储盒也包括在LCP中。这些提供了LCP程序存储器所需的空间。该板还具有一个双端口RAM。这为LCP和主机的驱动器控制板之间提供了必要的接口空间。用户可以通过访问许多系统功能和诊断可连接编程器。这个字母数字键盘很容易连接到板上。

在审查所有提供的存储和安装参数之前，不应开始设备安装。DS200SLCCG2A只能由经过驱动器板使用培训的用户操作。有关电路板布线的完整指南，请参考相应的器件手册和数据手册。该设备的制造商通用电气公司是该卡技术支持的zui初提供者。

DS200RTBAG3AEB GE 局域网通信板Mark V

Product description
DS200SLCCG2A is a LAN(Local Area Network) communication board. General Electric developed this board as part of the Mark V series drive board. A range of ge branded drives are designed to have this board installed in their drive cabinets. After the board is installed, the host gets the required LAN interface processing space. The board includes circuits required for DLAN network communication.

When the DS200SLCCG2A board is installed, the host driver provides two non-isolated and isolated communication circuits. The main component of the board is the LAN control processor. The processor is used to filter and process the signals sent to the circuit board. Two detachable EPROM storage boxes are also included in the LCP. These provide the space required for the LCP program memory. The board also has a dual-port RAM. This provides the necessary interface space between the LCP and the host's drive control board. Users can connect to the programmer by accessing many system functions and diagnostics. The alphanumeric keyboard is easy to attach to the board.

Device installation should not begin until all provided storage and installation parameters have been reviewed. The DS200SLCCG2A can only be operated by users trained in the use of the drive board. For complete guidance on board wiring, refer to the respective device manuals and data manuals. General Electric, the manufacturer of the device, was the initial provider of technical support for the card.
