A6140是一系列CMOS低压差(LDO）稳压器，可提供高达150mA的电流，同时仅消耗2ua的静态电流（典型)。
■输入工作范围为2.5V至36V，是多芯电池系统、两至六芯电池供电应用、9V碱性和一或两芯锂离子供电应用、母线电压电源系统和其他高直流电压系统的理想选择。
■宽的输入电压使其够很好地承受浪涌电压的冲击，保证输出电压的稳定性。
■轻载时仅2uA (典型)可降低整个系统的备用功耗，在多电池供电系统中具有较高的效益。
.A6140有SOT-23和SOT89-3封装。
●特征
m2uA静态电流(典型)
■输入工作电压范围:2.5V至36V.150mA输出电流
■低压差电压
■低温系数
±1%输出电压精度
■固定3.0V、3.3V、3.6V和5.0V输出■短路保护
■超温保护
■提供SOT-23和SOT89-3封装

A6140 9199-00058 CMOS低压差(LDO）稳压器 提供高达150mA的电流

The A6140 is a series of CMOS low voltage difference (LDO) regulators that deliver up to 150mA while consuming only 2ua of static current (typical).
■ With an input operating range of 2.5V to 36V, it is ideal for multi-cell systems, two - to six-cell battery powered applications, 9V alkaline and one - or two-cell Li-ion powered applications, bus-voltage power supply systems and other high DC voltage systems.
■ Wide input voltage makes it good enough to withstand the impact of surge voltage and ensure the stability of output voltage.
■ Only 2uA (typical) in light load can reduce the standby power consumption of the entire system, which has high benefits in multi-battery powered systems.
The A6140 is available in SOT-23 and SOT89-3 packages.
● Features
m2uA Static Current (Typical)
■ Input working voltage range :2.5V to 36V.150mA Output current
■ Low differential voltage
■ Low temperature coefficient
±1% output voltage accuracy
■ Fixed 3.0V, 3.3V, 3.6V and 5.0V outputs ■ Short circuit protection
■ Overtemperature protection
■ Available in SOT-23 and SOT89-3 packages
