产品说明
IS220PDOAH1A型号具有分立输出包的特征，设计时考虑了zui多可连接两个I/O以太网和其它分立输出端子板。该型号的一个特殊功能是，它可以控制多达12个继电器，并接受来自其他端子板的反馈信号。可用于该型号的典型继电器是固态继电器和电磁继电器。固态继电器与TRLYH1B、C、D和F端子一起使用，而电磁继电器与TRLYH1E板一起使用。该组件上接收的输入来自双RJ45以太网连接器和一个三针电源输入。

IS220PDOAH1A包中嵌入了一个处理器板。有多个处理器，包括但不限于状态指示led、用于监控和排序的本地电源、包括闪存和RAM存储器的高速处理器等等。关于处理器的所有信息可以在GEH-721G Mark VIe控制系统指南中找到，信息可以在第223页到第230页找到。

IS220PDOAH1A包具有输出使能特性。在向电池组供电的应用过程中，所有输出都将被禁用，直到完成大量内部自检。启用功能可以提供独立于命令的路径，这将确保继电器在电池组初始化和加电期间保持断开。

IS220PDOAH1A 3364940CSP2 离散输出组件
Product description
The IS220PDOAH1A model features a discrete output packet and was designed with up to two I/O Ethernet and other discrete output terminals in mind. A special feature of this model is that it can control up to 12 relays and receive feedback signals from other terminal boards. Typical relays available for this model are solid-state relays and electromagnetic relays. Solid-state relays are used with TRLYH1B, C, D, and F terminals, while electromagnetic relays are used with TRLYH1E boards. The input received on this component comes from dual RJ45 Ethernet connectors and a three-pin power input.

A processor board is embedded in the IS220PDOAH1A package. There are multiple processors, including but not limited to status indicating leds, local power supplies for monitoring and sorting, high-speed processors including flash and RAM memory, and more. All information about the processor can be found in the GEH-721G Mark VIe Control System Guide, information can be found on pages 223 through 230.

The IS220PDOAH1A package has the output enable feature. In applications where power is supplied to the battery pack, all outputs are disabled until extensive internal self-testing is completed. The enable function provides a command independent path, which will ensure that the relay remains disconnected during battery pack initialization and power-up.
