VMER-64 VME-用于2个PMC模块的载板

VMER-64 VME-用于2个PMC模块的载板

VMEbus系统易于扩展
向VMEbus系统添加多达2个PMC模块
所有PMC I/O信号都被发送到VMEbus连接器P2
根据IEEE P1386/ draft 2.0规范，适用于单宽度的两个PMC模块或双宽度的一个模块
可选P2引脚排列(VME-PMC-CADDY-32P2)
VME和PCI之间的高带宽连接
强大的VME PCI桥宇宙CA91C142
4级VME仲裁器，地址空间高达A32/D32
VME64扩展连接器
主或从功能
可靠的设计——易于操作且经济高效
专为低功耗和易于冷却而设计
在许多不同的工业应用中得到验证
符合IEEE P1386和IEEE 1014修订版D的标准接口和外形
可用的软件库
VME-PCI链路
VMEbus装配VME-PMC-凯迪是VME64基板，zui多可容纳两个单尺寸PMC模块或一个双尺寸模块。Tundra的VME-PCI bridge UNIVERSE II ca91c 142内部时钟频率为33 MHz，用于连接VMEbus。

VMEbus接口
CA91C142的设计允许电路板在VMEbus上作为从机或主机运行。作为主机，板支持4级仲裁器。VME-PMC-卡迪在VMEbus上以高达32位的数据宽度和32个地址信号运行。
VMEbus中断可以放在七条中断请求线上。根据VME64扩展，通过IEC 603-xx的两个160针VG连接器连接到VMEbus。红色LED表示有效的VMEbus中断请求，前面板上黄色LED表示VMEbus对电路板的访问。

VMER-64 VME-用于2个PMC模块的载板
The VMEbus system is easy to scale
Add up to 2 PMC modules to a VMEbus system
All PMC I/O signals are sent to VMEbus connector P2
According to the IEEE P1386/ draft 2.0 specification, it is suitable for two PMC modules of single width or one module of double width
Optional P2 pin arrangement (VME-PMC-CADDY-32P2)
High bandwidth connection between VME and PCI
Powerful VME PCI bridge Universe CA91C142
4-level VME arbitrator with up to A32/D32 address space
VME64 expansion connector
Master or slave function
Reliable design - easy to operate and cost effective
Designed for low power consumption and easy cooling
It has been proven in many different industrial applications
Standard interface and form element for IEEE P1386 and IEEE 1014 Revision D
Available software libraries
VME-PCI link
VMEbus Assembly VME-PMC-Cady is a VME64 substrate that can accommodate up to two single-size PMC modules or one dual-size module. Tundra's VME-PCI bridge UNIVERSE II ca91c 142 has an internal clock frequency of 33 MHz and is used to connect the VMEbus.

VMEbus interface
The design of the CA91C142 allows the board to run as a slave or host on the VMEbus. As a host, the board supports level 4 arbitrators. Vme-pmc-cadi operates on VMEbus with a data width of up to 32 bits and 32 address signals.
VMEbus interrupts can be placed on seven interrupt request lines. According to the VME64 extension, the VMEbus is connected via the two 160-pin VG connectors of IEC 603-xx. A red LED indicates a valid VMEbus interrupt request, and a yellow LED on the front panel indicates VMEbus access to the board.
