产品描述
IS215UCVEH2AB型号被标记为标准 Mark VI 控制器，被设计为 6U 高、单/双槽、单板计算机，通常用于操作涡轮机应用代码。此型号的位置位于具有 21 或 13 个插槽的 VME 机架中。当位于控制模块中时，它将通过VME总线与其他涡轮机I/O板进行通信。与此主板一起使用的典型操作系统是 QNX。QNX 系统是一个多任务、实时操作系统系统，专为高可靠性和高速工业应用而设计。

关于型号IS215UCVEH2AB的一个重要说明是，它只是Mark VI系统中使用的三个控制器之一，该型号可以取代其他控制器，但通常需要升级背板。该型号可以取代 ICVB 型号，但必须升级以太网电缆。

UCVE控制器可用于以下几种产品类型：

BOP， 工厂平衡

蒸汽

气

LM， 陆-海航衍生物

当控制器与此类产品一起使用时，它有一个特定的执行时间，zui高可达每秒十万个黑色或梯级。使用特定类型的应用软件时，可以在线修改软件，而无需重新启动。

IS215UCVEH2AB模型只是UCVE控制器的变体之一。UCVEH2 控制器有两种不同的存储器类型，分别是 32 MB 的 DRAM 或 16 MB 的闪存。有关此控制器的更多信息，请参阅 GEH-6421C 第二卷 Mark VI 涡轮机控制手册。

IS215UCVEH2AB 设计为 6U 高、单/双槽、单板计算机
Product description
The IS215UCVEH2AB model is marked as a standard Mark VI controller and is designed as a 6U tall, single/two-slot, single-board computer, typically used to operate turbine application codes. This model is located in a VME rack with 21 or 13 slots. When located in the control module, it will communicate with other turbine I/O boards via the VME bus. The typical operating system used with this motherboard is QNX. The QNX system is a multi-tasking, real-time operating system designed for high reliability and high-speed industrial applications.

An important note about the model IS215UCVEH2AB is that it is only one of three controllers used in Mark VI systems, and this model can replace the others, but usually requires an upgrade to the backplane. This model can replace the ICVB model, but the Ethernet cable must be upgraded.

UCVE controllers are available in several product types:

BOP, factory balance

steam

gas

LM, land-sea derivatives

When the controller is used with such products, it has a specific execution time of up to one hundred thousand black or steps per second. When using certain types of application software, the software can be modified online without restarting.

The IS215UCVEH2AB model is just one variation of the UCVE controller. The UCVEH2 controller comes in two different memory types, 32 MB DRAM or 16 MB flash. For more information on this controller, see the GEH-6421C Volume II Mark VI Turbine Control Manual.
