IS200VTCCH1CBB是通用电气为其Mark VI系统设计的热电偶输入板。Mark VI是专门为燃气轮机和蒸汽轮机的管理而设计的。该系统的设计是可扩展的，可用于大型和小型涡轮装置。Mark VI的硬件和软件设计都考虑到zui佳的涡轮性能，并专门为这些zui终用途而设计。该系统在关键控制上提供三次冗余备份。这通常发生在控制模块中，控制模块连接到HMI/操作员界面，允许用户访问系统数据、告警状态和维护工具。

IS200VTCCH1CBB标有几个代码，包括94VO,E99006,Type 6和2606。单板和前面板上均有GE标志。前面板通过螺丝连接连接到PCB上，包括三个LED组件，这些组件在板的顶部边缘附近一个一个堆叠。

IS200VTCCH1CBB接受E,J,K,S和T型热电偶。这些可以接地或不接地。热电偶距离控制柜zui远可达300米。zui大双向电缆电阻为450Ω。被认为“超出硬件限制”的热电偶被从扫描输入中取出，以防止数据影响其他输入。

IS200VTCCH1CBB有两个背板(P1和P2，)和四个其他连接器。电路板上有电感线圈或磁珠(L1到L19)。它还具有TP测试点，二极管，电阻和电容器。集成电路包括Xilinx Spartan XCS30 FPGA、IDT S35J双端口SRAM芯片、DSP TMS320C32PCMA50数字串行处理器和IDT S15Y CMOS静态RAM芯片。

MRP680489 IS200VTCCH1CBB 印刷电路板

The IS200VTCCH1CBB is a thermocouple input board designed by General Electric for its Mark VI system. The Mark VI is specifically designed for the management of gas and steam turbines. The system is designed to be scalable and can be used in both large and small turbine installations. Both the hardware and software of the Mark VI are designed with optimal turbine performance in mind and are specifically designed for these end uses. The system provides triple redundant backup on key controls. This usually occurs in the control module, which is connected to the HMI/ operator interface, allowing users to access system data, alarm status, and maintenance tools.

IS200VTCCH1CBB is marked with several codes, including 94VO,E99006,Type 6, and 2606. The GE mark is on the board and the front panel. The front panel is attached to the PCB via screw connections and consists of three LED components that are stacked one on top of the other near the top edge of the board.

The IS200VTCCH1CBB accepts type E,J,K,S and T thermocouples. These can be grounded or ungrounded. The thermocouple can be up to 300 meters away from the control cabinet. The maximum bidirectional cable resistance is 450Ω. Thermocouples that are considered "beyond hardware limits" are taken out of the scanned input to prevent data from affecting other inputs.

The IS200VTCCH1CBB has two backplanes (P1 and P2,) and four other connectors. On the circuit board are inductors or magnetic beads (L1 to L19). It also has TP test points, diodes, resistors and capacitors. Integrated circuits include Xilinx Spartan XCS30 FPGA, IDT S35J dual-port SRAM chip, DSP TMS320C32PCMA50 digital serial processor and IDT S15Y CMOS static RAM chip.
