网络自动化引擎(NAE)和网络集成引擎(NIE)是基于网络的、基于以太网的监控设备，用于监视和控制现场级楼宇自动化设备、HVAC设备和照明的网络。图1显示了一个典型的NAE55模型。
本文档主要介绍MS-NAE55xx-x和MS-NIE55xx-x两种型号发动机的安装方法，除非另有说明，以下统称为NAE55。

安装
安装NAE55时，请遵循以下原则:
•使用原集装箱运输NAE55，以减少对NAE55的振动和冲击损伤。
•确认所有随NAE55发货的部件。
数据保护电池和NAE55一起发货，但分开包装。
•请勿将NAE55跌落或受到物理冲击。
•请勿打开NAE55外壳(数据保护电池舱除外)。NAE55内部没有用户可维修的部件。部分包括
•1个NAE55
•一个数据保护电池
•安装说明书一份。所需材料和专用工具
•四个适合安装表面的紧固件(M4螺钉-欧洲，#8螺钉-北美)
•两个36厘米(14英寸)或更长的DIN导轨片，仅用于DIN导轨安装应用
•小型直刃螺丝刀，用于固定端子排中的通信导线
