MVI56-PDPMV1是一个ControlLogix平台兼容模块。该模块是一个Profibus DP V1兼容模块，作为Profibus网络中的主设备。该模块由Prosoft Technology开发，Prosoft Technology是罗克韦尔自动化的合作伙伴公司，开发Allen-Bradley PLC兼容模块。

MVI56-PDPMV1具有一(1)个光学隔离的RS485端口，支持PROFIBUS DP版本1协议。多达125个PROFIBUS从设备可连接到该端口，该端口也与PPROFIBUS中继器兼容。该模块能够配置高达1536个循环字节和1536个输出字节，并支持扩展诊断数据。

MVI56-PDPMV1支持的其他功能包括报警处理、同步和冻结命令，支持PROFIDrive版参数读写操作、多播和广播电报。

MVI56-PDPMV1具有嵌入式LED状态指示器，用于描述模块的运行状态。这些led指示灯包括就绪、运行、错误和令牌指示灯。

MVI56-PDPMV1 PROFIBUS通信模块安装在1756 ControlLogix底盘上。它占用机箱的一个插槽，从背板吸取800 mA @ 5VDC和3 mA @ 24VDC的电流。它的工作温度为0°C至60°C(32°F至140°F)，储存温度为-40°C至85°C(-40°F至185°F)。该模块必须安装在适当的外壳中，在相对湿度为5%到95%的情况下，从10赫兹到150赫兹的振动不超过5克，冲击不超过30克，无冷凝。

MVI56-PDPMV1模块是单槽模块，适合1756背板兼容。当连接到处理器时，它被识别为输入/输出模块。

此外，模块在处理器存储器中移动，以便在处理器和模块之间传输数据。通常，该模块用作PROFIBUS网络扫描器、PROFIBUS设备的数据传输媒介以及背板上的处理器数据存储器传输。

MVI56-PDPMV1模块的环境条件包括0至60摄氏度(32至140华氏度)的工作温度范围、-40至85摄氏度(-40至185华氏度)、10至150赫兹的5G抗振性、30G抗冲击性(不工作时为50G)和5至95%的相对环境湿度(非冷凝)。
