PM866 3BSE050200R1 控制器 支持CPU冗余

PM866 3BSE050200R1 控制器 支持CPU冗余

CPU板包含微处理器和RAM内存、实时时钟、LED指示灯、INIT按钮和CompactFlash接口。

PM866 / PM866A控制器的底板上有2个RJ45以太网接口(CN1、CN2)和2个RJ45串口(COM3、COM4)，用于连接到控制网络。其中一个串口(COM3)是带有调制解调器控制信号的RS-232C端口，而另一个端口(COM4)是隔离的，用于连接配置工具。控制器支持CPU冗余，提供更高的可用性(CPU、cex总线、通信接口和S800 I/O)。

简单的DIN导轨连接/分离程序，使用独特的滑动和锁定机制。所有的底板都有一个唯 一的以太网地址，它为每个CPU提供了一个硬件标识。该地址可以在TP830底板上的以太网地址标签上找到。

包包括:
2个PM866A, CPU
2个TP830，底板，宽度115mm
2个TB807, ModuleBus终端
1根TK850, cex总线扩展电缆
1根TK851, RCU-Link电缆
2块内存备用电池(4943013-6)每个CPU 1块

特点和优点
ISA安全认证-了解更多
可靠性和简单的故障诊断程序
模块化，允许逐步扩展
IP20级防护，不需要外壳
控制器可以配置800xA控件构建器
控制器通过EMC全认证
cex总线采用一对BC810 / BC820
基于zui佳通信连接标准的硬件(以太网，PROFIBUS DP等)
内置冗余以太网通信端口

PM866 3BSE050200R1 控制器 支持CPU冗余

The CPU board contains the microprocessor and RAM memory, real-time clock, LED indicator, INIT button, and CompactFlash interface.

The PM866 / PM866A controller has two RJ45 Ethernet ports (CN1 and CN2) and two RJ45 serial ports (COM3 and COM4) on the baseplate for connecting to the control network. One of the serial ports (COM3) is the RS-232C port with the modem control signal, while the other port (COM4) is isolated and used to connect to the configuration tool. The controller supports CPU redundancy and provides higher availability (CPU, cex bus, communication interface, and S800 I/O).

Simple DIN rail connection/separation procedure with unique sliding and locking mechanisms. All baseboards have a unique Ethernet address, which provides a hardware identity for each CPU. This address can be found on the Ethernet address label on the TP830 baseboard.

The package includes:
2 PM866A, CPU
2 TP830s, base plate, width 115mm
2 TB807s, ModuleBus terminals
1 TK850, cex bus expansion cable
1 TK851, RCU-Link cable
2 memory spare batteries (4943013-6) One for each CPU

Features and advantages
ISA Security Certification - Learn more
Reliable and simple troubleshooting program
Modular, allowing for gradual expansion
IP20 protection, no case required
The controller can be configured with the 800xA control builder
The controller is fully certified by EMC
The cex bus uses a pair of BC810 and BC820
Hardware based on the best communication connectivity standards (Ethernet, PROFIBUS DP, etc.)
Built-in redundant Ethernet communication port
