T8403C ICS 可信的TMR 24 Vdc数字 输入模块40通道

T8403C ICS 可信的TMR 24 Vdc数字 输入模块40通道

Trusted®TMR 24 Vdc数字输入模块接口到40个现场输入设备。容错是通过模块内40个输入通道中的每一个的三模冗余(TMR)架构实现的。
每个场的输入是三倍的，输入电压是用sigma-delta输入电路测量的。将所得到的场电压测量值与用户可配置的阈值电压进行比较，以确定所报告的场输入状态。当在现场开关处安装线路监控装置时，该模块可以检测现场电缆的断路和短路。线路监控功能为每个输入通道独立配置。三倍电压测量，加上板载诊断测试，提供全面的故障检测和容错。
该模块提供板载事件序列(SOE)报告，分辨率为1毫秒。状态的变化触发SOE条目。状态由电压阈值决定，可以在每个通道的基础上配置。

特性
•每个模块40个三模冗余(TMR)输入通道。
•全面、自动诊断和自检。
•可选择线路监控每通道检测开路和短路现场接线故障。
•2500v脉冲耐受光/电隔离屏障。
•板载事件序列(SOE)报告，分辨率为1ms。
•通过专用的Companion(邻)Slot或SmartSlot(多模块一个备用槽位)配置，支持在线热替换模块。
•每个通道的前面板输入状态led指示输入状态和现场接线故障。
•前面板模块状态led指示模块运行状况和运行模式(Active、Standby、connected)。

T8403C ICS 可信的TMR 24 Vdc数字 输入模块40通道

The Trusted®TMR 24 Vdc digital input module interfaces to 40 field input devices. Fault tolerance is achieved through the three-mode redundancy (TMR) architecture of each of the 40 input channels within the module.
The input for each field is tripled, and the input voltage is measured using a sigma-delta input circuit. The resulting field voltage measurement is compared with a user-configurable threshold voltage to determine the reported field input state. When line monitoring devices are installed at field switches, the module can detect field cable breaks and short circuits. The line monitoring function is configured independently for each input channel. Triple voltage measurement, coupled with onboard diagnostic testing, provides comprehensive fault detection and fault tolerance.
The module provides onboard event sequence (SOE) reports with a resolution of 1 millisecond. A change in state triggers the SOE entry. The state is determined by the voltage threshold and can be configured on a per-channel basis.

peculiarity
• 40 three-mode redundant (TMR) input channels per module.
• Comprehensive, automated diagnostics and self-tests.
• Optional line monitoring each channel detects open - and short-circuit field wiring faults.
•2500v pulses withstand optical/electrical isolation barriers.
• Onboard Event sequence (SOE) reports with a resolution of 1ms.
• Support for online hot replacement modules through dedicated Companion(adjacent)Slot or SmartSlot(multiple modules in one standby slot) configuration.
• Front panel input status leds for each channel indicate input status and field wiring faults.
• Front panel module status led indicates module health and operating mode (Active, Standby, connected).

T8403C ICS 可信的TMR 24 Vdc数字 输入模块40通道
