Allen Bradley 的 22C-D038A103 AC Powerflex 400 Drive 在 25 马力时的额定输出功率为 18.5 kW，安培数为 38，在 45 至 50 摄氏度之间的 5 度温度变化下保持一致。推荐的电机电路保护为 140M-F8E-C45，带有 100-C60 接触器，zui小外壳体积为 9086 平方英寸。它的功耗约为 606 Open IP20 Watts，并具有 50 个保险丝。

22C-D038A103 是一款框架 D 驱动器，外壳防护等级为 IP30，NEMA/UL 1 型，无法兰安装。将 I/O 信号端接到驱动器时，zui大电线尺寸为 33.6 mm 平方（或 2 AWG）。（电线不能小于 8.4 平方毫米或 8 AWG）。接线扭矩为 5.1 N-m，或 45 磅到一英寸。

本机有一个集成的 LCD 键盘，两排，每排 16 个字符和 5 个 LED 指示灯。这个集成键盘允许本地监控和控制，例如启动和速度命令。通过该装置的特色辅助电机控制系统，zui多可以与中央电机并排控制三个额外的线路启动电机，中央电机将由 22C-D038A103 Powerflex 驱动器直接控制。使用该系统可以产生高达 400% 的输出，其中驱动控制电机和所有三个附加电机都以zui大速度运行。该系统也可以实现自动化，一旦需求增加超过第 一台电机的能力，额外的电机就会开始运行。

该串行 （RS485） 驱动器支持 FLN、DSI、Modbus RTU 和 Metasys N2 作为标准通信协议。它还支持多种可选协议，包括 ControlNet、LonWorks、Ethernet/IP 和 Device Net。

22C-D088A103适用于额定功率为18.5kW或25.0 HP的交流电机。该可调频率交流驱动器的输入电压要求为 340-528VAC，三相，输入电流为 40 安培，频率范围为 48-63 Hz。该驱动器支持在外壳内进行面板安装应用，该外壳可提供足够的保护，免受腐蚀性空气或气体、水、灰尘、油和油脂等常见污染物的侵害。该变频器还需要外部保护装置，如直流母线扼流圈、EMC滤波器、交流线路电抗器、谐波滤波器、保险丝和其他电气保护装置，以zui大限度地延长变频器的使用寿命。

22C-D038A103 一款 PowerFlex 400 变频驱动器

Allen Bradley's 22C-D038A103 AC Powerflex 400 Drive has a rated output of 18.5 kW at 25 HP, with 38 amps and a consistent temperature variation of 5 degrees between 45 and 50 degrees Celsius. The recommended motor circuit protection is 140M-F8E-C45 with 100-C60 contactors and a minimum housing volume of 9086 square inches. It has a power consumption of about 606 Open IP20 Watts and has 50 fuses.

The 22C-D038A103 is a frame D driver with IP30 housing protection, NEMA/UL Type 1, flangeless mounting. When connecting the I/O signal end to the driver, the maximum wire size is 33.6 mm square (or 2 AWG). (Wires cannot be smaller than 8.4 square millimeters or 8 AWG). Wiring torque is 5.1 N-m, or 45 pounds to an inch.

The unit has an integrated LCD keyboard with two rows of 16 characters each and five LED indicators. This integrated keyboard allows local monitoring and control, such as startup and speed commands. With the unit's featured auxiliary motor control system, up to three additional line-starting motors can be controlled side-by-side with the central motor, which will be directly controlled by the 22C-D038A103 Powerflex drive. Up to 400% output can be generated using this system, in which the drive control motor and all three additional motors operate at maximum speed. The system can also be automated, with additional motors coming into operation as soon as demand increases beyond the capacity of the first motor.

The serial (RS485) driver supports FLN, DSI, Modbus RTU, and Metasys N2 as standard communication protocols. It also supports several optional protocols, including ControlNet, LonWorks, Ethernet/IP, and Device Net.

The 22C-D088A103 is suitable for AC motors rated at 18.5kW or 25.0 HP. The input voltage requirements for this adjustable frequency AC driver are 340-528VAC, three-phase, input current is 40 amps, and frequency range is 48-63 Hz. The drive supports panel mount applications in a housing that provides adequate protection from corrosive air or common contaminants such as gas, water, dust, oil and grease. The inverter also requires external protection devices such as DC bus choke, EMC filters, AC line reactors, harmonic filters, fuses and other electrical protection devices to maximize the service life of the inverter.
